• Model NO.：GD-H1478
• Origin：Made in China
• HS Code：9031809090
• Production Capacity：100sets,Month

Basic Info.

Model NO. GD-H1478 Origin Made in China HS Code 9031809090 Production Capacity 100sets/Month

Product Description

ASTM D7098 Lubricant Oxidation Stability Tester by Thin-Film Oxygen Uptake (TFOUT)



Introduction:

The ASTM D7098 Lubricant Oxidation Stability Tester is suitable for the determination of the oxidation stability of gasoline engine oil by High Temperature Thin-Film Oxygen Uptake (TFOUT).


Specifications:

1. In line with the standard ASTM D7098
2. Power supply: AC220V±10%, 50Hz
3. Heating power: ≤ 3.4KW
4. Temperature control range: room temperature~200 °C
5. Temperature control accuracy: ± 0.1 °C
6. Digital precision pressure sensor accuracy: ± 2 ‰
7. Motor speed: 100 ± 3r/min
8. Overall dimensions: 600mm*750mm*850mm


Features:

1. The instrument adopts foreign advanced technology, and the microcomputer automatically detect, calculate and control, no staff is required to be on duty during the entire test, the degree of automation is high. Real-time communication with the host computer, the connection is simple and reliable.
2. The temperature and pressure can be proofread at any time to ensure the accuracy of pressure and temperature.
3. Automatically record data and test results during the test.
4. The past records can be queried, compared, and the pressure curve can be printed out.
5. Automatically determine the pressure inflection point and automatically end the test.
6. Imported rotating device, stable speed and low noise.
7. Two groups of oil samples can be tested at the same time.
8. Imported mercury slip ring, long life, reliable performance.
