• Model NO.：MP-2
• Display：Digital
• Control：Electric
• Weight：0-100Kg
• Power Source：AC220V
• Grinding/Polishi Disc Diameter：200mm
• Grinding Disc Rotating Speed：50-1000rpm(Stepless Speed)
• Motor：Yss6324 250W
• Dimension：400*730*310mm
• Operating Voltage：AC 220V,50Hz
• Warranty：12 Months
• Transport Package：Standard Exporting Plywood Case
• Specification：400*730*310mm
• Trademark：OBT
• Origin：China
• HS Code：9024109000
• Production Capacity：100 PCS,Month

Basic Info.

Model NO. MP-2 Display Digital Control Electric Weight 0-100Kg Power Source AC220V Grinding/Polishi Disc Diameter 200mm Grinding Disc Rotating Speed 50-1000rpm(Stepless Speed) Motor Yss6324 250W Dimension 400*730*310mm Operating Voltage AC 220V,50Hz Warranty 12 Months Transport Package Standard Exporting Plywood Case Specification 400*730*310mm Trademark OBT Origin China HS Code 9024109000 Production Capacity 100 PCS/Month

Product Description

MP-2B Double Discs Polishing Machine

MP-2 Specimen Grinder Polisher
1.Application and Feature of Grinding-Polishing Machine
Model MP-2 Metallographic specimen grinding & polishing machine is equipped with double discs, and it can finish grinding or polishing with two different speeds. The rotating speed of left disc (pre-grinding disc) is 450 rpm and right disc (polishing disc) is 600 rpm. With double disc and different grinding and polishing materials, it can realize the process of rough grinding, fine grinding, rough polishing and finishing polishing. This machine features easy operation and economical applying. It is the ideal specimen preparing instrument for using in factories, scientific research institutes and laboratories of colleges.

2. Main Specifications:

Model	MP-2
Grinding Disc Diameter	230mm
Polishing Disc Diameter	200mm
Grinding Disc Rotating Speed	450 rpm(left) 600rpm(right) can be ordered
Motor	YC7124  370 W
Dimension	700×600×278mm
Weight	50kg
Operating voltage	AC 220V,50Hz
