ASTM F2029 Medical Foil Heat Seal Performance Tester for Lab Use
Pubtester Instruments Co., Ltd.- Sealing Temperature：Room Temperature ~ 300 °c
- Sealing Pressure：50~ 700 Kpa
- Temperature Accuracy：± 0.2 Degree
- Dwell Time：0.1 ~ 999.9s
- Temperature Uniformity：± 1 Degree
- Sealing Area：330 mm X 10 mm
Base Info
- Model NO.：HSR-01
- Transport Package：Veneer Case
- Trademark：Pubtester
- Origin：Jinan, Shandong
- Production Capacity：10 Sets,Quarter
Description
Extended
ApplicationsSealing Surfaces Various types of sealing surfaces can be customized upon user's requirements. Jelly Cups Jelly cups can be sealed with special testing accessories. Soft Plastic Pipes Soft plastic tubes can be sealed from one end and become packaging containers
Standards
ASTM F2029, QB/T 2358, YBB 00122003
Configuration
Standard Configuration: Instrument, Pedal Switch
Optional Parts: Micro-Printer, Sample Cutter 15#, Silicon Rubber Plate, High-temperature Welding Cloth
NOTE: 1.The gas supply port of the instrument is Φ6 mm PU Tubing;
2. Customers will need to prepare for gas supply.
FAQ
Are you a manufacturer or trading company?
We are the manufacturer and trading combo, which specialize in material testing instruments such as plastic package, medical device, facial mask, protective clothing and pharmaceutical package, etc. We located in Jinan, Shandong, China.
Do you have any certificate?
We have obtained CE certificate, passed ISO 9001, IPMS management system certificates, and have 18 utility model patents and 4 software copyright certificates.
How about the installation?
The user's manual specifies the installation requirements with details. We will advise the relative information in advance, such as power supply, space, required temperature, humidity, etc.
Do you have after-sales service?
We will carry out the equipment inspection before delivery. If the machine does not work properly, we can make a remote control service to help dealing with the failure. We promise to reply within 24 hours and provide solutions within 2 working days.
How about the warranty?
Our warranty is 12 months, lifelong free of charge! User just bear the materials cost and express charge out-of-warranty period.
How long does the delivery time?
For the regular machine, 3-5 working days. For the customized one, 30 days or so.
Applications
| Specifications | HSR-01 |
| Sealing Temperature | Room temperature ~ 300 °C |
| Sealing Pressure | 50~ 700 Kpa (Depend on sealing area) |
| Dwell Time | 0.1 ~ 999.9s |
| Temperature Accuracy | ±0.2 °C |
| Temperature Uniformity | ± 1 °C |
| Heating Mode | Double Heating Surfaces (Independent Control) |
| Sealing Area | 330 mm x 10 mm (Customization Available) |
| Gas Supply Pressure | 0.7 MPa~0.8MPa (Not in Supply Scope) |
| Port Size | Φ6 mm PU Tubing |
| Instrument Dimension | 400 mm (L) × 320 mm (W) × 400 mm (H) |
| Power Supply | AC 220V 50Hz / AC 120V 60HZ |
| Net Weight | 40 kg |
Standards
ASTM F2029, QB/T 2358, YBB 00122003
Configuration
Standard Configuration: Instrument, Pedal Switch
Optional Parts: Micro-Printer, Sample Cutter 15#, Silicon Rubber Plate, High-temperature Welding Cloth
NOTE: 1.The gas supply port of the instrument is Φ6 mm PU Tubing;
2. Customers will need to prepare for gas supply.
