• Model NO.：KU-504S
• Company Philosophy：Integrity, Innovation, Service, Win-Win
• Temp. Range：-70~150c
• Humidity：20~90% R.H
• Pressure Range：Normal Pressure ~ 5kpa
• Interior Dimension：W800 mm * H900 mm * D700 mm
• Exterior Dimension：W1200 mm * H2060 mm * D1900 mm
• Device Cooling Method：Water Cooled
• Buck-Boost Time：About 30min
• Transport Package：Strong Plywood Case, Meet International Standards
• Specification：Standard and Customized
• Trademark：KOMEG
• Origin：Dongguan China
• HS Code：90321000
• Production Capacity：800PCS,a Year

ModelKU-504SInner Size (D*W*H)Cm80*70*90Total Power ( KW )16Chamber Volume ( L )504PerformanceTemp range-0 °C~ +150 °CTemp constancy±0.5 %Temp deviation≥ 100 °C , ±3.0 °C( at constant pressure with empty load )< 100°C , ±2.0°C( at constant pressure with empty load )Cooling rate0.7°C~ 1.0°C /min ( Overall average )Pressure rangeConstant pressure  ~ 1kPaPressure constancyWhen  ≥ 40kPa, ±2kPa,     4kPa ~ 40pKa  ±0.5kPa,   when ≤ 4kPa, ±0.1kPaDepressurization rateConstant pressure ~ 1kPa≤30mins ( Normal temp )Pressure recovery rate10kPa/Min(adjustable )MaterialExterior materialCold-rolled steel sheet(Rust proof&Plastic Spray treated)/Stainless Steel plateInterior materialStainless steel ( SUS304 )Pressurized partsHigh quality steel plate(Rust proof & Plastic spray treated)  Insulation materialHigh quality glass woolCooling SystemCompressorSemi-Hermetic CompressorCooling ModeWater cooledTemp regulating methodBalanced Temperature & Humidity Control System  (BTHC )PumpRotary vane type vacuum pumpHeaterIron-chrome wire heaterSight windowCircular viewing glass incorporating heat generatorTemp SensorPt-100ControllerTouch Screen Controller  Safety DevicesOver pressure, over heat and over current protection for compressor, over temp. protection,
over load protection for blower,   Hydraulic and Water lack Protection, leakage protection, phase-lack protection, Pump failure alarmStandard AccessorySight window, Cable Port( 1 located on the left side), Baffle, Baffle frame*2  PowerAC380V/50Hz, 3Phase 5 wires+ Ground Wire. Note: 1. We reserve the right to change specifications without prior notice  2. Customized sizes and configurations available
Photos show
