Test Instrument

Laboratory Analysis Instrument of Sulfur Content in Coal Analyzer

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
  • Power Source:AC220V
  • Product Name:Sulfur Content in Coal
  • Test Sample:Coal, Steel and Various Minerals
  • Analytical Time of Sample Combustion:3-5min, 45s at 700 Celsius, 2-4min at 1050celsius
  • Temperature Control:1150 Celsius(Adjustable)
  • Transport Package:Wooden Case for Total Sulfur Content in Coal Anal

Base Info

  • Model NO.:GD-6F
  • Trademark:GOLD
  • Origin:China
  • Production Capacity:100 Sets, Month

Description

1Measuring range of sulfur0-100%2Analytical time of sample combustion3-5min, 45s at 700ºC, 2-4min at 1050ºC, automatic determination of titration end-points3Temperature control 1150ºC±5ºC (adjustable)4Accuracyclass 1.0 during 0-1100ºC5Thermocoupleexternal WRP (S) Platinum-10Rhodium/Platinum (PtRh10-Pt)6Heater carborundum tube;7length of the high temperature zone≥90mm8Velocity of temperature rising25-30ºC/m, reaching 1050ºC in less than 30 minutes9Electrolytic cell400ml10Instrument stabilitybeing stable in five minutes after started11power supply220V±20%   50Hz

Features:
Compared with others similar ones, this sulfur content analyzer has such features:
1.Automatic determination of titration end-points, less experiment time
2.PID control of the furnace heating current, automatic adjustment of the amount, twice as much the life time of carborundum tube as traditional controllers (automatic current control from small to big)
3.Electronic switch, high reliability
4.No electrolysis because of the sequence of turning on and turning off
5.Automatically open electrolysis
6.High automation, small size, the ideal sulfur analyzer in laboratories


Certificate:
Laboratory Analysis Instrument of Sulfur Content in Coal AnalyzerExhabition:
Laboratory Analysis Instrument of Sulfur Content in Coal Analyzer
About us:
Chongqing Gold Mechanical & Electrical Equipment Co.,Ltd is a high-tech enterprise for researching, designing, developing and producing scientific and measuring instruments. With its continuous drawing of lessonas, unremitting innovation and borrowing of advanced technology from both at home and abroad, our company is now becoming a professional manufacture of oil tester,laboratory instrument,road building instrument.
Laboratory Analysis Instrument of Sulfur Content in Coal Analyzer
