• Model NO.：GD-1094
• Communication：RS232
• Printer：Thermosensitive Micro-Printer
• Light Source：LED Lighting
• Amplitude Adjustment：120~250mm(Every 5mm Adjustable)
• Speed Adjustment：2~4times , S
• Regular Time：115~125s
• Quiescent Time：5 Minutes
• Warranty：1 Year
• Transport Package：Wooden Case
• Origin：Chongqing of China
• HS Code：9031809090
• Production Capacity：200 PCS , Month

Basic Info.

Model NO. GD-1094 Communication RS232 Printer Thermosensitive Micro-Printer Light Source LED Lighting Amplitude Adjustment 120~250mm(Every 5mm Adjustable) Speed Adjustment 2~4times / S Regular Time 115~125s Quiescent Time 5 Minutes Warranty 1 Year Transport Package Wooden Case Origin Chongqing of China HS Code 9031809090 Production Capacity 200 PCS / Month

Product Description

Aviation Fuel Testing ASTM D1094 Water Reaction of Aviation Fuels Tester


Introduction:

The Water Reaction of Aviation Fuels Tester conforms to ASTM D1094 Standard  Test Method for Water Reaction Tester of Aviation Fuel.
The Water Reaction of Aviation Fuels Tester is suitable for testing the presence of water-miscible components in aviation gasoline and turbine fuels, and the effect of these components on volume change and on the fuel-water interface.


Features:


1.The Water Reaction of Aviation Fuels Tester adopts gas drive to realize high-speed vertical reciprocating motion, domestic initiative.

2.The apparatus adopts microcomputer control, accurately control the experimental period and experimental route, calculate the number of the round-trips.

3.The apparatus provides different kinds of experimental form, route, period and other parameters are flexible and adjustable.

4.The apparatus shows quiescent time and alarm prompt after the experiment.

5.The apparatus provides soft light source to make the result observation convenient, compliant with experiments under different environment

6.The apparatus saves data automatically and gorge line is connected with upper computer, can print and upload data automatically.

7.Easy operation with attractive appearance and low noise.



Parameters:


1.Power voltage: AC220V ± 10%, 50Hz

2.Power:40W

3.Communication terminal: RS232

4.Printer: Thermosensitive micro-printer

5.Light source: LED lighting

6.Amplitude adjustment:120~250mm( every 5mm adjustable)

7.Speed adjustment:2~4Times / s

8.Regular time:115~125s

9.Quiescent time:5min

10.Ambient requirements:Temperature:10~40ºC;Humidity≤85%
