• Model NO.：JBW-300B
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC380V
• Transport Package：Plywood Exporting Package
• Specification：360kg 1.32CBM
• Trademark：HST
• Origin：Jinan, Shandong, China
• HS Code：902410900
• Production Capacity：1000 Sets,Month

Computer Control AutomaticMax. Impact Energy300 J / 150 J500 J / 250 J500 J / 750 JMin. Reading Values1 J2 JImpact Speed5.2 m/s5.4 m/s5.9 m/sPre-rising Angle Of The
Pendulum150°Angle Accuracy±0.1°Specimen Bearer Span40+0.2 mmRound Angle Of The JawR 1.0~1.5 mmRound Angle Of Impact EdgeR 2.0~2.5 mm
(Special Order: R8±0.05 mm)R2.0-2.5 mm,
R8.0±0.05 mmThickness Of Impact Blade16 mmThe Distance Between The
Pendulum Shaft And Impact
Point750 mm800 mmStandard Specimen Dimension10 mm * 10 (7.5 or 5) mm * 55 mmImpact Pendulum Configuration150 J, 1 PC;
300 J, 1 PC250 J, 1 PC;
500 J, 1 PC500 J, 1 PC;
750 J, 1 PCHost Appearance Dimensions2124mm * 600mm * 1340mm2450*1200
*2455mmWeight480 KG610 KG2330 KGPower Supply3phs, 380V, 50Hz

4.Features:
4.1 Fully automatic, sample feeding, auto position the sample; high efficiency;
4.2 Pendulum rising, impact, sample feeding, position, free releasing is realized automatically by
   easy PC mouse click;
4.3 Safety pin guaranties the impact action, standard protection shell to avoid any accident.
4.4 Pendulum will automatically rising and ready for next impact action after specimen breakout.
4.5 With two pendulums (big and small), PC software to display the energy loss, impact tenacity,
   rising angle, test average value etc. test data and result, also the curve display available;
   with calculation and report printing function. The dial scale can show test results too.
