Fully Automatic Insulation Oil Bdv Tester Transformer Oil Dielectric Strength Testing Machine 100kv

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
  • Product Name：Transformer Oil Bdv Tester
  • Test Standards：IEC156, Is6792, BS5874, ASTM D1816 , ASTM D877
  • Application：Test Breakdown Voltage Value of Transformer Oil
  • Output Voltage：AC 0V~80kv (100kv for Choice)
  • Rate of Voltage Rise：0.5kv,S, 2kv,S, 3kv,S, 5kv,S± 5%
  • Display 1：LCD

Base Info

  • Model NO.：GDYJ-502
  • Printer：Micro Printer, PC Connection
  • Max. Test Times：9
  • Stir Time：0~999s
  • Wait Time：0~999s
  • Power Supply：AC220V, 50Hz,60Hz(Support Customize)
  • Transport Package：Plywood Case for Oil Bdv Tester
  • Specification：50kg
  • Trademark：GOLD
  • Origin：Chongqing, China
  • HS Code：9030849000
  • Production Capacity：500 Pieces,Month

Description

No.Item NameQTY1GDYJ-5021 Unit2Power line1 Unit3Grounding line1 Unit4Test vessel1 Unit5Electrodes(Mushroom, Flat and Spherical type)1pair each6Feeler gauge(1mm,2mm,2.5mm,4mm)1pc each7Stirrer2 units8High voltage column1pair9USB-RS232 connection line1 Unit10Thermal print paper2 units11Fuse(5A/3A)2 units/2 units12Instruction manualInstruction manual13disk1unit14Inspection report1unit
Customer Visit:
Fully Automatic Insulation Oil Bdv Tester Transformer Oil Dielectric Strength Testing Machine 100kv

Feedback:

Fully Automatic Insulation Oil Bdv Tester Transformer Oil Dielectric Strength Testing Machine 100kv
