• Model NO.：GD-0719-1 Wheel-Track Tester
• Loading Method：Dynamic Load
• Display：Digital
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Top
• Transport Package：Wooden Case
• Specification：1320mm*750mm*1400mm
• Trademark：GOLD
• Origin：China
• Production Capacity：200unit,Month

 Standards:  industrial standard T0719-2011 in  JTG E20-2011Grinding rate:   (42±1)times/min(one-way) Test wheel movement distance:   230mm±10mm Rubber hardness:       78±2 (international standard hardness) Loading device:  0.7MPa±0.05Mpa (at 60 °C), adjustable range 0.5~1.2 (Mpa)a Displacement measuring range:     0mm~30mm Displacement measuring accuracy:    ±0.01mm Wheel track test time:    60 minutes~240 minutes.

Control range of the incubator:

 room temperature ~ 80 ° C (can be set arbitrarily)

 Work mode: water immersion test and non-immersion test Temperature measurement accuracy:  ±0.1ºC Environment control accuracy:

±1 °C

Test mode temperature control accuracy:

 ±0.5ºC Temperature measurement channels:  2 channel

The number of test pieces that can be made at the same time:

 1  Number of health care of the test piece:  3  Roller motion mode:  Test wheeled Power supply AC380V, 50Hz, 10A, three-phase four-wire system, with a neutral line

Dimensions of the whole machine:

1520mm × 770mm × 1700mm (length × width × height) 350kg



Test die size:

300mm × 300mm × 50mm (standard) / 30mm ~ 100mm (adjustable)



• Gold Equipment Service:

If you face any problems in future during testing process we promise we will give you a reply within 48 hours and

solution provide within 3 working days.

We can offer operation video and English operation muanual. We can provide video-con.

Onsite Service:

1.Device installation; 2.Equipment Operation Test Technology training;3.Equipment Calibration;4.Daily maintenance and maintenance of equipment

Free technical training for visiting factories

24-hour Online contact

Free software upgrades

Free information:steel tensile test

1.Product Instruction;2.Product operation instruction/video;3.Experiment Test (test application, test report)

Device Problem Handling:

1. Social media 24 hours online communication;2. Mail Seamless Docking;3. Video Conferencing;4. Artificial free door-to-door service









• Exhibition



We have developed sales channels in many countries such as UAE, Saudi Arabia, Iran, Malaysia, Thailand, Pakistan,

India, Germany, Belgium, USA, Mexico, Kenya,

Nigeria, South Africa and other countries worldwide. And we have gained strong advantage and high reputation in international market.

After several years' development, our products have become high intelligent and wide coverage.
And our company has become one of the leading manufacturer of petroleum testing instrument and electrical testing instrument.



Brazil ANALITICA LATIN AMERICA 2017 2017 Photos Show



• Packing

Goods are packed in veneer case, which is firm and safe for oversea shipment.






Please feel FREE to contact us if you have any needs. And welcome to visit our OFFICIAL WEBSITE at:

http://chinainstrument.en.made-in-china.com

Moblie/+8615998955437
