50kn Digital Cbr Test Machine
Zhuozhou Tianpeng Imp. & Exp. Trade Co., Ltd.- Transport Package：Wooden Case
- Specification：400 x 350 x 800mm
- Trademark：C-TECH
- Origin：China Mainland
Base Info
- Model NO.：CTM-02
- HS Code：90248000
- Production Capacity：50 Sets,Month
Description
Basic Info.
Model NO. CTM-02 HS Code 90248000 Production Capacity 50 Sets/MonthProduct Description
50KN Digital CBR Test Machine
This 50KN Digital CBR Test Machine conforms to Standard: BS1377-4, ASTM D1883 and GB T0134-1993.
Features:
1. 10.1 inch color touch screen display with curve display, data saving and printing functions.
2. Arbitrary set the test deformation record points and loading speed, to meet the needs of different test standards.
3. with data processing capabilities, can automatically calculate the CBR value.
4. Servo motor control with software speed feedback, stepless adjustment of loading speed.
5. Built-in mini-printer can print data stream list and test results.
6. Optional digital dial gauge, to further improve the test accuracy.
7. Optional PC test software, using PC software for independent testing and output detailed reports.
Technical Parameters
Capacity: 0-50KN
Deformation: 0-25.00mm
Load speed: 0-20mm/min
Motor: 220V, 0.37KW, 1440rpm
Overall dimension: 400 x 350 x 800mm
