• Model NO.：MD-SYJ200LA
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC220V
• Capacity Selection：2-200kg
• Display Method：LCD Display in English, Thin Film Touch Button
• Unit Switching：Kg, Lb, N
• Load Cell：Tension Force and Compression Force Sensor
• Test Width：150mm
• Tension Space：500mm
• Displacement Test Accuracy：Within ±0.5% of The Indicated Value
• Test Bench Safety Device：up and Down Stroke Limiting Device
• Fixture Configuration：a Set of Tension Fixture
• Dimension：450*500*1400mm
• Transport Package：Standard Export Packing
• Specification：450*500*1400mm
• Trademark：Minder
• Origin：China
• Production Capacity：100sets,Month

Basic Info.

Model NO. MD-SYJ200LA Control Computer Control Weight 100-500Kg Power Source AC220V Capacity Selection 2-200kg Display Method LCD Display in English, Thin Film Touch Button Unit Switching Kg, Lb, N Load Cell Tension Force and Compression Force Sensor Test Width 150mm Tension Space 500mm Displacement Test Accuracy Within ±0.5% of The Indicated Value Test Bench Safety Device up and Down Stroke Limiting Device Fixture Configuration a Set of Tension Fixture Dimension 450*500*1400mm Transport Package Standard Export Packing Specification 450*500*1400mm Trademark Minder Origin China Production Capacity 100sets/Month

Product Description

Product Description
This machine is suitable for tension, compression, bending, shearing, peeling, tearing, etc, of materials and product in textile, rubber, plastic, synthetic leather, tape, adhesive products, plastic film, composite materials, electronics, metal and other industries. A variety of tests to determine the quality of the products.
Technical parameter

Capacity selection	2-200kg
Display method	LCD display in English, thin film touch button
Unit switching	Kg, lb, N
Load cell	tension force and compression force sensor
Test width	150mm
tension space	500mm
Test speed range	Stepless speed regulation of 50-300 mm/min and five-gear speed regulation
Displacement test accuracy	Within ±0.5% of the indicated value
Breakpoint ratio setting	0-99%, users can set the appropriate breakage time according to different materials
Test bench safety device	Up and down stroke limiting device
Fixture configuration	A set of tension fixture
Dimension	450*500*1400mm
Machine	60kg
Power supply	220V/50Hz
