50kn Automatic Asphalt Marshall Stability Compression Tester

Zhuozhou Tianpeng Imp. & Exp. Trade Co., Ltd.
  • Maxcapacity：50kn
  • Display：Digital
  • Control：Manual Control
  • Power Source：AC220V
  • Product Name：Marshall Stability Tester
  • Model No：Ld-5

Base Info

  • Model NO.：LD-5
  • Test Rate：50.8mm,Min
  • Transport Package：Wooden Case
  • Trademark：C-TECH
  • Origin：China
  • HS Code：90248000
  • Production Capacity：500sets,Month

Description

Basic Info.

Model NO. LD-5 Test Rate 50.8mm/Min Transport Package Wooden Case Trademark C-TECH Origin China HS Code 90248000 Production Capacity 500sets/Month

Product Description

Specifications:
Marshall stability tester

sTandard:
asTM d1559, aasHTO T245, nF P98-251-2,
Cnr nO. 30, asTM d5581 (6" dIa. sPECIMEns)

Model No.LD-5
Max Capacity:50kN
Test Rate:50.8mm/min
Cross Head Travel:70mm
Displacement Probe Travel:15mm
Verticial Clearance:300mm
Horizontal Clearance:270mm
Dimension(mm):590(L)*310(W)*750(H)
Approx. Weight:90kgs
Power:220V, 50/60Hz, 1 ph, 0.5Hp,2.3A

50kn Automatic Asphalt Marshall Stability Compression Tester
