• Model NO.：GD-QX-G
• Loading Method：Dynamic Load
• Display：Digital
• Control：Computer Control
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Under
• Transport Package：Wooden Case
• Specification：210mm*350mm*400mm (Length * width * height)
• Trademark：GOLD
• Origin：China
• Production Capacity：200units,Month

1.    Measurement range:

(1)Aviation gasoline: 86.0~105.0/MON
(2) Gasoline for motor vehicles:National standard: 65.0~110.0/RON    National-V standard: 70~115.0/RON
Blended gasoline: 75.0~120.0/RON     Light gasoline:50.0~85.0 /MON
Isomerized gasoline: 85.0~120.0/RON   Arene gasoline:90.0~120.0/RON
Ethanol:   E93: 92.0~95.0/RON        E97: 95.0~99.0/RON       Judgement: 60.0~120.0/RON

(3) Automobile diesel fuels:25~75/CN(cetane number);   20~80/CI(cetane index)

2. Accuracy:

Aviation gasoline: ≤± 1.5/MON     Gasoline for motor vehicles:  ≤±1.5/RON  ≤± 1.5/MON

 Automobile diesel fuels: ≤±2.6/CN  ≤±2.6/CI   Regression sample retest: ≤±0.5/RON   ≤±0.5/MON
 Regression sample measurement: ≤±1.5/RON  ≤± 1.5/MON
 Calibration accuracy: ≤±0.2/RON    ≤±0.2/MON

3.Precision(confidence level 95%):Reproducibility:  ≤±0.5/RON      Repeatability: ≤±0.2/RON4.Minimum scale:  0.1/RON    0.1/MON   0.1/CI
5.Response time:  1s6.Test result: LCD display, it can store and print7.Power supply: AC(220±10%)V,(50±1)Hz8.Working environment:10ºC~35ºC;relative humidity:≤85%9.Dimension:330 mm×240 mm×170 mm





I. Main technical specifications



1.With the innovative high precision digital sensor,strong anti-interference capability,less deviation,

high precision,good reproducibility and  repeatability.

2.With the automatic returning technical platform to realize the value transformation from the national standard

CFR tester to SYD-QX-G and be geared with the China standard GB/T5487 and ASTM D2699,improve the

measurement accuracy and expand the measurement range.

3.Establishing the technical platform to jointly do the auxiliary calculation with the traditional petroleum detecting

instruments(Distillation tester,Densimeter),it makes sure that the cetane index of diesel fuels and the cetane number

be measured more accurately,and could gear with the technical requirements GB/T386.

4.It adopts the color LCD touch display,with simple and convenient man-machine conversation screen,and guide

the user to operate correctly according to the hints on the screen display.

5. It adopts automatic value assignment calibration technology. The calibration procedure is simple, the method is

scientific, and the calibration result is accurate and reliable.

6. Gasoline octane number test:A test can display research octane number, motor octane number and antiknock

index at the same time. Diesel fuels test can display the cetane number,to input standard density and mid-boiling

point can get cetane index, to derive the correct the cetane number automatically.

7. It needs less test oil, every test only needs 150 ml samples; The test time is short, every test time is in 1 min.
