Constant Temperature and Humidity Chamber Lab Test Equipment

Guangdong Komeg Industrial Co., Ltd.
  • After-sales Service：24 Hours on Line Services
  • Warranty：12 Months
  • Type：Material Testing Machine
  • Weight：100-500Kg
  • Power Source：AC380V
  • Temp. Range：-70oc~+150oc

Base Info

  • Model NO.：KMH series
  • Humidity Range：20-98%R.H.
  • Temp. Constancy：+,-0.5oc
  • Humidity Constancy：+,-2.5%R.H.
  • Temp. Uniformity：+,-2.0oc
  • Humidity Uniformity：+,-5.0%R.H.
  • Heat up Time：-70 Oc~+100 Oc Within 45mins
  • Pull Down Time：+20 Oc~-70 Oc Within 60mins
  • Refrigeration System：Hermetic Compressor, Stage Refrigeration System
  • Exterior Material：Baked Painting Steel or Stainless Steel(SUS304)
  • Transport Package：Strong Plywood Case, Meet International Standards
  • Specification：Standard and Customized
  • Trademark：KOMEG
  • Origin：Dongguan, China
  • HS Code：90321000
  • Production Capacity：1000 Sets,Year

Description

Environmental Temperature and Humidity ChamberSecifications ( at +20ºC room temp.  Or+25ºC water temp with empty load)ModelKMH-R seriesKMH-L seriesKMH-S series150R225R408R800R1000R150L225L408L800L1000L225S408S800S1000STemp. range -20ºC~150ºC -40 ºC~+150ºC -70ºC~+150ºC Interior sizelW(mm)600700700100010006007007001000100070070010001000H(mm)600700750100010006007007501000100070075010001000D(mm)460480800800100046048080080010004808008001000Exterior sizeW(mm)880980980128012808809809801280128098098012801280H(mm)17301890194021602160173018901940216021601890194021602160D(mm)14001460174017501950140014601740175019501460174017501950Power(KW)5.867.512.812.87.57.58.514.514.59.510.618.518.5Weight(KG)240280400500580250300420530600330450550650Humidity uniformity±3.0%R.H±5.0%R.H±3.0%R.H±5.0%R.H±3.0%R.H±5.0%R.HHeat up time -20ºC~+100ºC,within 35 min -40ºC~+100ºC, within 45 min -70ºC~+100ºC,within 60 minPull down time +20ºC~-20ºC, within 45 min +20ºC~-40ºC , within 60 min +20ºC~-70ºC,within 80 minStandard accessoriesSight window*1, cable port(portΦ50mm)*1, shelves*2, chamber lamp*1, power cable *2mSafety device  (standard)No fuse breaker, over pressureover heat and over current protection for compressor,Over temp. protect, over load protect of blower, dry heat protectionControl SystemBalanced Temperature & Humidity Control SystemRefrigeration systemAir Cooled (Water Cooled Type is option)Hermetic compressor,Single stage refrigeration system                      CFC-Free refrigerant(HFC-507/HFC-23)ControllerPanel:7-inch LCD Touch panel,    Chinese or English display selectableOperation model :Program or fix point runningMemory capacity :120programs,1200steps,All repeat 999 cycles, part repeat 99 cyclesHumidity Range20~98%R.HTemp. constancy±0.5ºC   Humidity constancy±2.5%R.HTemp. uniformity±2.0ºCInterior materialStainless Steel Plate(SUS 304)Exterior materialBaked Painting Steel Or Stainless steel(SUS304)Insulation materialRigid polyurethane Foam and Glass Fiber WoolAmbient Temp.+5ºC~+35ºCWiring methodAC 380±10%50Hz ,3 phase 4 wires +Ground WiresNote: 1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available
 Standard configuration:

Sight window*1, cable port(portΦ50mm)*1, shelves*2, chamber lamp*1, power cable *2m
No fuse breaker, over pressure,over heat and over current protection for compressor,
Over temperature protection, over load protect of blower, dry heat protection

Optional accessories:

Cable Port: Φ100mm cable port is available
Shelves
Ro-type water purifier:R-80/day
Provide to keep the humidifying heater and wet bulb wick free from scale.
Inner glass door with operation port
A glass door can be provided behind the main door so that specimens can be observed. Two operation ports of 130mm
diameter are used for handing specimens inside the chamber without opening the glass door.
Dehumidifier
The rotation regenerating dehumidifier M-120 ensures precise control of low humidity (5ºC 5%RH) for electrostatic
reliability tests.
Temperature and humidity recorder
-100 to +150ºC/0 to 100%RH 100mm with effective width 100mm and 2 pen
Temperature 1 pen and humidity 1 pen.
-100 to +150ºC/0 to 100%RH 100mm with effective width 100mm and 6 dots
Temperature 3 dots and humidity 1 dot.
-100 to +150ºC/0 to 100%RH 100mm with effective width 180mm and 12 dots
Temperature 6 dots and humidity 6 dots.
Defrosting circuit
The chamber automatically detects and melts the frost on the evaporator when operating below 0ºC.
Liquid or infection
In order to rapidly decrease the temperature inside the chamber, a cylinder of liquid can be connected the chamber.
