• Model NO.：CY-DWC300-A
• Trademark：CYKY
• Origin：Zhengzhou, China
• Production Capacity：5000pieces,Month

Name

Automatic diamond wire cutting machine

Model

CY-DWC300-A

Features

1. The cutting size can reach 12". (max)

2. The main motor drives the diamond cutting line to move downward at a constant speed, and the material is fixed on the worktable to ensure stable cutting.

3. The worktable can be adjusted by 360° rotation manually or through program control.

4. The pneumatic tensioning system is adopted and imported pneumatic components are used to make the tensioning force more stable and reliable.

5. PLC program control system and large-size touch screen make the operation simple and quick.

6. Various tooling fixtures can be designed according to your needs.

Functions

1. Ceramic materials: alumina ceramics, zinc oxide ceramics, zirconia ceramics, target ceramics, honeycomb ceramics, semiconductor ceramics, conductive ceramics, non-conductive ceramics, etc;

2. Crystal material: graphite, silicon crystal (solar polysilicon, monocrystalline silicon), sapphire, alumina crystal, infrared glass crystal, alumina crystal, silicon carbide crystal, cesium iodide crystal, etc.;

3. Glass materials: chalcogenide glass, optical glass, quartz glass, infrared glass, glass tube, etc.;

4. Metal materials: iron, aluminum, copper, titanium alloy, magnesium alloy and other metals and alloys, non-ferrous metals (zinc sulfide, ferrite), etc.;

5. Composite materials: PVC board, carbon fiber composite material, glass fiber composite material, etc.

6. Rock materials: precise sections of natural rocks, jade, meteorite, Peicui, agate and other high-value materials; geological optical slices, geological thin sections (sedimentary rocks, magmatic rocks, metamorphic rocks, ores), etc..

7. Thermoelectric materials: bismuth telluride, lead telluride, silicon germanium alloy, etc.

8. Infrared optical materials: zinc selenide, zinc sulfide, silicon, germanium and other crystals

9. Biomedical materials:Bioplasticization specimen sections (human animal organs, jaw joint sections of soft and hard tissues, implant observation, tooth crown and   bridge, teeth and other histological specimens);

Combined sections of soft and hard tissues in orthopedics department (fresh tissues and hard tissues such as   femur, hip joint and vertebral body, bone histological samples with implants, etc.);

Cardiac and cerebrovascular stent section, stone section and other medical tissue sections;

Parameters

1. Power supply: 220 V 50 Hz;

2. Power: < 550W (max);

3. Spindle motor: AC frequency conversion motor, Power 400W;

4. Y, Z, R axis motor: precision stepping motor;

5. Cutting wire speed: 0-8m / s adjustable, digital display;

6. Total length of cutting line: ≤ 150m;

7. Cutting line diameter: ≤ 0.45mm;

8. Y axis travel: ≤ 300 mm, digital display;

9. Z axis travel: ≤ 300 mm, digital display;

10. Y, Z axis feed indication accuracy: 0.01mm;

11. Worktable angle: 0-360°, resolution 0.01°, digital display;

12. Repeated positioning accuracy of worktable: < 0.032°

13. Cutting sample size: Ø 300 mm × 300 mm (max);

14. Tension system: pneumatic tension, tension pressure adjustment range 0-1mpa;

15. Safety control device: self stop and emergency stop switch of line break

Specifications

Size: 1000mm×900mm×1700mm

Weight

About 500kg
