Electroscope Function Test Device GDY-35
HV Hipot Electric Co., Ltd.- Model No.：GDY-35
- Usage：Withstand Voltage Test Set
- Voltage grade：10kV, 35kV and below electroscope
- Interval distance of electrode (mm)：10kV-100,35kV-430
- H1 (mm)：>1500
- Ring diameter (mm)：550
Base Info
- Model NO.：GDY-35
- Ball diameter (mm)：60
- Delivery time：15 working days
- Transport Package：Wooden Case
- Specification：ISO, SGS
- Trademark：HV Hipot
- Origin：Wuhan China
- Production Capacity：3000 Pieces,Year
Description
Basic Info.
Model NO. GDY-35 Ball diameter (mm) 60 Delivery time 15 working days Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China Production Capacity 3000 Pieces/YearProduct Description
It is suitable for accurate test of the electroscope function, easy to operate.Test device apply to 10KV, 35KV, 66KV, 110KV, 220KV and 330KV respectively.
FeaturesTable 1 Electroscope with contact electrode extension
| KV | Interval distance of electrode (mm) | H1 (mm) | Ring Diameter (mm) | Ball Diameter (mm) |
| 10 35 | 100 430 | >1500 | 550 | 60 |
| 66-110 220-330 | 650 850 | >2500 | 1050 | 100 |
| 500 | 1250 | >3500 | 1550 | 150 |
Table 2 Electroscope without contact electrode extension
| KV | Interval distance of electrode (mm) | H1 (mm) | Ring Diameter (mm) | Ball Diameter (mm) |
| 10 35 | 300 | >1500 | 550 | 60 |
| 66-110 220-330 | 1000 | >2500 | 1050 | 100 |
| 500 | 1250 | >3500 | 1550 | 150 |
Device Structure
GDY-35 (Suitable for 10kV, 35kV): H1 is a single insulated tube with a length of 1500mm, the top is equipped with a spherical electrode with a diameter of 60mm. H2 is a single insulated tube with a length of 1300mm, H2 supports a ring electrode with a diameter of 550mm, H3 supports the electroscope.
