• Model NO.：PN-MF
• Specification：ISO
• Trademark：PNSHAR
• Origin：Hangzhou, Zhejiang
• HS Code：90248000
• Production Capacity：300sets,Year

Basic Info.

Model NO. PN-MF Specification ISO Trademark PNSHAR Origin Hangzhou, Zhejiang HS Code 90248000 Production Capacity 300sets/Year

Product Description

Features:
1. Simple and easy operation;
2. Accurate temperature control using PID;
3. Fine machining medium flutting wheel, good flute.
1. Description:
This medium fluter is used to flute the paper samples by means of two flutting rolls. Afterwards, the samples are tested in the crush tester for evaluation of the CMT (Concora Medium Test) and CCT (Corrugated Crush Test).
2. Specification:

ITEM	SPECIFICATION
Power supply:	AC220V±10%,10A, 50Hz;
Radius of teeth at peak:	1.50+/-0.1mm;
Radius of teeth at base:	2.00+/-0.1mm;
Depth of teeth:	4.75+/-0.05mm;
Working speed:	4.5r/min;
Temperature resolution:	1ºC;
Working temperature can be adjusted:	Room temperature to 200ºC;
Working pressure:	adjustable in (49-108)N;
Standard working temperature:	(175±8)ºC.
Dimension:	530 × 400 ×474mm
Net weight:	about 80kg.
Standard equipment prepared :	"A" Flute;
