Model Ht-225D Digital Concrete Test Hammer
Zhuozhou Tianpeng Imp. & Exp. Trade Co., Ltd.- Display Type：Digital
- Communication：USB2.0
- Power：13.7V Li-ion
- Strike Hammer Stroke：75mm
- Transport Package：wooden box or others
- Specification：GB,T9138-1988, JJG817-93, JGJ,T23-2001
Base Info
- Model NO.：HT-225D
- Trademark：Tianpeng
- Origin：China
- HS Code：90248000
- Production Capacity：20000pcs,month
Description
Basic Info.
Model NO. HT-225D Trademark Tianpeng Origin China HS Code 90248000 Production Capacity 20000pcs/monthProduct Description
Model HT-225D Digital Concrete Test HammerHT-225D Concrete Test Hammer applied to inspect compressive strength for general building components, bridges and all kinds of concrete components (include in slabs, beams, columns, bridges for concrete).
Specificaitons:
| Measuring strength ranges: | 2.207J(0.225Kgf. M) |
| Normal impact energy: | 10-60MPa |
| Strike hammer stroke: | 75mm |
| The friction force of pointer slider: | 0.5N± 0.8N |
| Spherical radius of strike rod: | 25mm± 1mm |
| The rebound values calibrated on steel anvil: | 80± 2 |
| Dimensions: | Φ 54*278mm |
