• Model NO.：GD-2806H
• Softening Point Tester：ASTM D36 Ring-and-Ball Softening Point Tester
• Softening Point：Automated Softening Point Tester for Bitumen
• Temperature Resolution：0.1c
• Test Samples：It Can Do Two Samples or Four Samples
• Heating Rate：It Will Be Adjusted to 5.0+,-0.5c, Min
• Heating Power：600 W
• Computer Port：RS-232c Communication Port
• Cubage of Beaker：900ml
• Warranty：1 Year
• Transport Package：Wooden Case
• Trademark：GOLD
• Origin：Chongqing of China
• HS Code：9031809090
• Production Capacity：100sets,Month

Basic Info.

Model NO. GD-2806H Softening Point Tester ASTM D36 Ring-and-Ball Softening Point Tester Softening Point Automated Softening Point Tester for Bitumen Temperature Resolution 0.1c Test Samples It Can Do Two Samples or Four Samples Heating Rate It Will Be Adjusted to 5.0+/-0.5c/ Min Heating Power 600 W Computer Port RS-232c Communication Port Cubage of Beaker 900ml Warranty 1 Year Transport Package Wooden Case Trademark GOLD Origin Chongqing of China HS Code 9031809090 Production Capacity 100sets/Month

Product Description

Automated Softening Point Tester for bituminous materials using water or glycerol as bath liquid



Introduction of Automated Softening Point Tester:

1. The Automated Softening Point Tester is designed and made as per GB/T4507 Standard Test Method for Softening Point of Bitumen of national standard of People's Republic of China , T0606 -2011 Softening Point Test (Ring-and-Ball Apparatus) in the industrial standard of People's Republic of China JTG E20-2011 Specification and Test Methods of Bitumen and Bituminous Mixture for Highway Engineering and ASTM D36 Standard Test Method for Softening of Bitumen (Ring-and-Ball Apparatus).
2. The Automated Softening Point Tester is used to determine softening point of petroleum asphalt, coal pitch, liquid petroleum asphalt, and various of asphalts.
3. The Automated Softening Point Tester can be widely used for asphalt manufacturing companies, highway and bridge construction companies, relative colleges and universities, and scientific research institutes.



Features:

1. This instrument adopts advanced technologies such as computer intelligent control, laser automatic detection, LCD touch screen and micro printer.
2. It has linear temperature heating, uniform bath stirring and accurate test results.
3. It can do four samples or two samples at a time.
4. The Automated Softening Point Tester(ASTM D36) has functions of automatic completion of sample testing and automatic printing of test results, it is an automatic and intelligent testing instrument for asphalt softening point with high degree of automation, fast and convenient testing, accurate and reliable testing results.



Specifications:

1. Power supply: AC(220V±10%)V, 50Hz
2. Measurement range:
    (1) Heating medium: distilled water(softening point <=80 ºC) +5 ºC~+80ºC
    (2) Heating medium: glycerin (softening point > 80 ºC) 32 ºC~160 ºC.
3. Temperature resolution: 0.1 ºC
4.Test samples: It can do two samples or four samples.
5. Heating rate: it will be adjusted to 5.0±0.5 ºC/ min automatically after three minutes
6. Heating power: 600 W
7. Computer port: RS-232C communication port
8. Cubage of beaker: 900 ml
9. Ambient temperature: 15ºC~35ºC
10. Relative humidity: ≤85%
11.Maximum power consumption: 700 W
12.Dimension: 400mm×300mm×490mm (L*W*H)


Automated Softening Point Tester in our laboratory!
