• Model NO.：GD-0165B
• Refrigeration：No
• Single/Double Unit：LCD
• Atmospheric/Vacuum：Vacuum
• Usage：Determine The Distillation Characteristics
• Delivery Time：10 Working Days(If Urgent, We Can Push)
• Test Parameter：Petroleum Products
• Transport Package：Wooden Case for Vacuum Distillation Apparatus
• Trademark：GOLD
• Origin：Chongqing, China
• Production Capacity：100 Sets, Month

Basic Info.

Model NO. GD-0165B Refrigeration No Single/Double Unit LCD Atmospheric/Vacuum Vacuum Usage Determine The Distillation Characteristics Delivery Time 10 Working Days(If Urgent, We Can Push) Test Parameter Petroleum Products Transport Package Wooden Case for Vacuum Distillation Apparatus Trademark GOLD Origin Chongqing, China Production Capacity 100 Sets/ Month

Product Description

Semi-automatic Vacuum Distillation Apparatus with Touch Screen


Summary
  Semi-automatic vacuum distillation apparatus is designed and made as per industrial standard SH/T 0165-92 Standard Test Method for Distillation Characteristics of Petroleum Products with High Boiling Point Range by Vacuum Process.
Semi-automatic vacuum distillation apparatus is suitable to determine the distillation characteristics of wax oil, lubricating oils and other petroleum products with high boiling point range.


I. Main technical features
1. Semi-automatic vacuum distillation apparatus adopts single-chip machine technology to control the vacuum pressure automatically.
2. Semi-automatic vacuum distillation apparatus adopts high accuracy temperature sensor to detect the steam temperature automatically. No need to observe it by naked eye.
3. Semi-automatic vacuum distillation apparatus adopts LCD technology, can input, modify and show parameters and control them by touch screen.
4. Semi-automatic vacuum distillation apparatus equips a micro-printer to save and print test results.


II. Main technical specifications
1. Power supply: AC(220±10%)V , 50Hz.
2. Heating furnace of distillation flask:  (0~1000)W, adjustable
3. Heating power of receiver: 350W,automatically controlled.
4. Temperature control point of receiver:  Ambient to 99ºC±3ºC,adjustable.
5. Setting range of vacuum residual pressure:  (2~99) mmHg±0.1mmHg.
6. Measurement range of vacuum residual pressure:

(2~150) mmHg±0.1mmHg, automatic pressure maintenance
7. Volume of buffer vessel: 1000ml
8. Illumination light in the air bath :Energy saving lamp
9. Working condition:  Ambient temp.:(5~35)ºC   RH:< 85%
10. Dimension:  600mm×230mm×605mmI,SYD-0165B Semi-automatic Vacuum Distillation Apparatus Accessories and Documents List


Related Products:

Parameter	GD-6536A	GD-6536B	GD-6536C	GD-0165
Standards	ASTM D86	ASTM D86	ASTM D86	ASTM D1160
Measurement range	Ambient temperature~400ºC	0~60ºC	0~60ºC	Ambient temperature~100ºC
Precision	±0.5ºC	±0.5ºC	±0.5ºC	±1ºC
Refrigeration	No	Yes(compressor)	Yes(compressor)	No
Single/Double unit	Double	Double	Single	LCD
Atmospheric/Vacuum	Atmospheric	Atmospheric	Atmospheric	Vacuum
