- Model NO.：GD-SF6
- Warranty：One Year
- Product Name：Sf6 Synthesized Tester for Sale
- Transport Package：Wooden Case
- Specification：250*150*300mm3
- Trademark：GOLD
- Origin：Chongqing, China (Mainland)
- HS Code：9013809000
- Production Capacity：100 Sets , Month
| Purity | Measuring range: 0%~100% |
| Accuracy: ±0.5% |
| Measuring time: < 2min |
| Dew point | Measuring range: -80ºC~+20ºC |
| Accuracy: ±0.5ºC(-80ºC~-60ºC) |
| Response time(+20ºC) | 63% need 5S, 90% need 45S (-60ºC~+20ºC) |
| 63% need 10S, 90% need 240S (+20ºC~-60ºC) |
| H2S | Measuring range: 0~200ppm |
| The minimum detectable amount: ≤0.1ppm |
| Accuracy: ±0.5% |
| Stability: 0~200ppm |
| Repeatability: ≤2% |
| SO2 | Measuring range: 0~200ppm |
| The minimum detectable amount: ≤0.1ppm |
| Accuracy: ±0.5% |
| Stability: 0~200ppm |
| Repeatability: ≤2% |
| HF(optional) | Measuring range: 0~20ppm |
| The minimum detectable amount: ≤0.01ppm |
| Accuracy: ±0.5% |
| Stability: 0~20ppm |
| Repeatability: ≤2% |
| CO(optional) | Measuring range: 0~1000ppm |
| The minimum detectable amount: ≤1ppm |
| Accuracy: ±0.5% |
| Stability: 0~1000ppm |
| Repeatability: ≤2% |
| Temperature | -40ºC~+60ºC |
| Humidity | 0~100%RH |
| Power supply | AC 220V |
| Built-in rechargeable battery |
| Battery performance | Charging time: 20 hours; can work for 10 hours |
| Weight | 5kg |
| Dimension | 250×150×300mm3 |
| Working temperature | -40ºC~+80ºC |
