• Model NO.：HTXZ
• Certification：CE
• Customized：Customized
• Color：Red
• Transport Package：Wooden Case
• Trademark：HV TEST
• Origin：China
• HS Code：9030899090
• Production Capacity：60 Sets Per Month

Basic Info.

Model NO. HTXZ Certification CE Customized Customized Color Red Transport Package Wooden Case Trademark HV TEST Origin China HS Code 9030899090 Production Capacity 60 Sets Per Month

Product Description

Brief introduction
BPXZ-HT makes the reactor and tested capacitor in resonant by adjusting the frequency of the power source, to get high voltage and heavy current from measured equipment. Now it is a new method and trend for high voltage test and widely used.
BPXZ-HT uses special SPWM digital wave-generate chip, resolution is 16 bits, the frequency adjustment fineness could be 0.1Hz if the frequency was 20~300Hz; adopts sine asynchronous fixed wave carrier modulation, to ensure the waveform output is good in the whole frequency range; adopts advanced IPM module, ensure the stability and safety of the device under minimum weight.

Products features 1. Small in volume, light in weight.2. This system need one person to carry the device less than 30KG, two people less than 60KG. Suitable to carry on site.3. Power supply, Single phase: 220V or 380V, convenient to get power on site.4. Reactor uses epoxy cast, beautiful and reliable, suit for all kinds of cables.5. 110kV and above voltage level cable withstand voltage test use oil-immersed reactors, when the weight of single machine is more than 100kg, optional dedicated small electric cranes
 Technique parameters

Rated output voltage	≤0~220kV(AC effective value)
Output frequency	30~300Hz
Resonate voltage waveform	Sine wave, distortion ≤1.0%
Full load working time	Continuous working time: 60min
System quality factor	≥20 under maximum load
Frequency adjustment	0.1Hz
Instability	≤0.01%
Power supply	Single phase :220V or three phase :380V±10%, frequency:50Hz±5%

Configuration table of cable (≤ 35kV) voltage withstand device:

Model	Control cabinet	Reactor(dry type)	Excitation transformer (dry type)	Divider	Application
BPXZ-HT44/22	2.5kW	1A/22kV:2 sets	2.5kVA/1kV	25kV	10kVcable≤1km
BPXZ-HT88/22	4kW	2A/22kV:2 sets	4kVA/1kV	25kV	10kVcable≤2km
BPXZ-HT132/22	6kW	2A/22kV:3 sets	6kVA/1/3kV	60kV	10kVcable≤3km 35kVcable≤1km
BPXZ-HT176/22	7.5kW	2A/22kV:4 sets	7.5kVA/1/3kV	60kV	10kVcable≤4km 35kVcable≤1km
BPXZ-HT264/22	10kW	2A/22kV:6 sets	10kVA/1/3kV	60kV	10kVcable≤6km 35kVcable≤2km
BPXZ-HT330/22	15kW	2.5A/22kV:6 sets	15kVA/1/3kV	100kV	10kVcable≤8km 35kVcable≤2km
BPXZ-HT640/32	25kW	2.5A/32kV:8 sets	25kVA/1/3/5kV	200kV	10kVcable≤10km 35kVcable≤4km 110kVcable≤1km

Configuration table of cable (≥110kV)voltage withstand device :

Model	Control cabinet	Reactor (oil immersed)	Excitation transformer (oil immersed)	Divider	Application
BPXZ-HT1300/130	50kW	5A/130kV:2 sets	50kVA/3/5kV	150kV	35kVcable≤2km 110kVcable≤2km
BPXZ-HT2600/130	100kW	5A/130kV:4 sets	100kVA/3/5/10kV	220kV	35kVcable≤3km 110kVcable≤3km 220kVcable≤1.5km
BPXZ-HT3200/220	160kW	4A/220kV:4 sets	160kVA/5/10kV	160kV	110kVcable≤5km 220kVcable≤3km
BPXZ-HT6400/220	320kW	8A/220kV:4 sets	320kVA/5/10kV	320kV	110kVcable≤10km 220kVcable≤5km 500kVcable≤1km

Common problem
1. Is your company a sales company or a manufacturer?
Wuhan Huatian Electric Power Automation CO., LTD.is an industrial and trade enterprise, with its own  factory, self-produced and self-sold. We were founded in 2004 and have fifteen years of production experience. Our company has reliable production lines, test rooms and R&D centers.

2. Whether the goods are in stock, whether they can be customized, and how long the delivery time is.
After the goods have been ordered, we can be made to order according to the special requirements of customers by using the latest technology. The delivery time is usually within 10 working days if there are no accidents.

3. Is the quality guaranteed?
In order to ensure quality, we use imported components in large quantities. After three times of quality inspection, the goods can be sent out, and the export is uniformly packed in non-fumigation wooden boxes.

4. What are the after-sales terms?
We offer free consulting service, one year warranty, and adopt various methods such as email communication, video calls, technology door-to-door, aiming to solve any after-sales problems in a timely manner.

5. What are the cooperative countries or regions?
Products have been successfully exported to the United States, Brazil, Australia, Russia, the Netherlands, Indonesia, Bangladesh, Iran, India, Saudi Arabia, Mongolia, Japan and other countries and regions. In the United States, India, Vietnam and other regions have cooperative distributors, can provide thoughtful services.
