• Model NO.：GDJ-T
• Number of Channel：8 Channel
• Sampling Volume：0.2ml-100.0ml
• Sampling Speed：5ml,Min~80ml,Min
• Resolution：<10%
• Coincidence Deviation Limit：10000 Grain,Ml
• Pressure：0.8 MPa
• Vacuum：0.1 MPa
• Communication：by RS232 Port
• Transport Package：Wooden Case
• Origin：Chongqing China
• HS Code：9031809090
• Production Capacity：200 PCS , Month

Basic Info.

Model NO. GDJ-T Number of Channel 8 Channel Sampling Volume 0.2ml-100.0ml Sampling Speed 5ml/Min~80ml/Min Resolution <10% Coincidence Deviation Limit 10000 Grain/Ml Pressure 0.8 MPa Vacuum 0.1 MPa Communication by RS232 Port Transport Package Wooden Case Origin Chongqing China HS Code 9031809090 Production Capacity 200 PCS / Month

Product Description

Auto Particle Counter for Particle Counting of hydraulic and lubricating oil


Introduction:

When an oil maintenance system is installed, it is equally important to continuously measure oil cleanliness. The GDJ-T Oil Particle Counter optimized for this purpose and is available with a wide range of features and functions.

GDJ-T Oil Particle Counter design with Laser Extinction Technology, is designed to measure the particles in the oil, which include hydraulic oil, lubricating oil, transformer oil, insulating oil, turbine oil, gear oil, engine oil, kerosene and so on. It can be used in aviation, spaceflight, electric power, petroleum, chemical industry, transportation, port, metallurgy, machinery, automobile manufacturing and other fields. It also can be used to measure particles in organic liquid and polymer solution.


Technical Data:

Size range                 1µm~100µm
Number of channel          8channel, size can be set free(in the range of selected curve)
Sampling volume            0.2ml-100.0ml
Sampling speed             5ml/min~80ml/min
Resolution                  <10%
Coincidence deviation limit   10000 grain/ml
Calibration                 according to GB18854
Relative humidity           max.70%
Ambient Temperature       5ºC-40ºC

Fluid Specifications:

Pressure                  0.8Mpa
Vacuum                   0.1Mpa

Electrical Connection:

Communication             RS232 port
Power Supply              AC220V±10%; 50Hz; ≤200W

Main Assembly:

The instrument is composed by the instrument and a pump.


Welcome to visit our laboratory!
