• Model NO.：55-C0193,B
• HS Code：90248000
• Production Capacity：1000 Pieces,Month

Basic Info.

Model NO. 55-C0193/B HS Code 90248000 Production Capacity 1000 Pieces/Month

Product Description

Curing of Specimen
    Both ASTM and EN specifi cations require the specimens to be left in the mould for the fi rst 16 hours up to a maximum of three days, protected against shock, vibration and dehydration at a temperature from 20 ± 5°C or 25 ± 5°C in hot climates (EN method) and 16 to 27°C (ASTM method).
    After the removal from the moulds the specimens have to be stored in a moist condition at 20 ± 2°C (EN) or 23 ± 1.7°C (ASTM) with a relative humidity 95%. Alternatively they can be cured in water at the same  temperature.

Model 55-C0193/A plastic curing tank is designed for curing concrete cubes and cylinders.
Temperature range: from ambient to +40°C
Wattage: 3000 W
Capacity: 1000 litres
Overall dimensions: 700x1700x850 mm
Weight approx.: 50 kg
