• Model NO.：GD-H1160
• Temperature Control Method：Import Pid Digital Display Thermostat
• Temperature Control Accuracy：60+,-0.1c
• Heating Method：Electric Heating Tube
• Working Unit：4 Groups
• Timing Mode：Digital Timer
• Total Power：2500W
• Transport Package：Wooden Case
• Trademark：GOLD
• Origin：Chongqing China
• HS Code：9031809090
• Production Capacity：100sets,Month

Basic Info.

Model NO. GD-H1160 Temperature Control Method Import Pid Digital Display Thermostat Temperature Control Accuracy 60+/-0.1c Heating Method Electric Heating Tube Working Unit 4 Groups Timing Mode Digital Timer Total Power 2500W Transport Package Wooden Case Trademark GOLD Origin Chongqing China HS Code 9031809090 Production Capacity 100sets/Month

Product Description

Rust Preventing Characteristics Oil Bath ASTM D665 for Lubricant


Introduction:

The Rust Preventing Characteristics Oil Bath is used to determine the lubricant's ability to prevent rusting of metal surfaces. The Rust Preventing Characteristics Tester can be applied to steam turbine oils, gear oils, hydraulic oils and other types of inhibited mineral oils. A steel test specimen is immersed in a heated mixture of sample oil and water which is stirred continuously during the test. After the test period the specimen is examined for rusting.



Features:
1. High-power solid-state voltage regulator controls the heating rate.
2. The Rust Preventing Characteristics Oil Bath adopts PID temperature control technology with high temperature control precision.
3. The instrument adopts touch keyboard for easy operation.
4. Each group of experiments uses a separate single-motor operation to get rid of the shortcomings of the traditional pulleys driving several sets of tests and the noise is large.
5. The instrument uses stainless steel as the bath body to prevent corrosion.
6. Separate clamping ferrules to ensure no turbulence during the experiment.
7. Integrated structure, easy to move.
8. The instrument is made of cold-rolled steel plate, and the surface is electrostatically sprayed, which is corrosion-resistant and easy to clean.
9. The welding of the instrument adopts the welding technology, no solder joints, and the appearance is beautiful and generous.


Application:
1. Lubricating oil production
2. Inspection department


Reference Standards:
1. GB/T11143 Standard Test Method For Rust-Preventing Characteristics Of Inhibited Mineral Oil In The Presence Of Water.
2. ASTM D665 Standard Test Method for Rust-Preventing Characteristics of Inhibited Mineral Oil in the Presence of Water.


Technical Parameters:

1	Model number	GD-H1160
2	Applicable standard	GB/T11143, ASTM D665
3	Temperature control method	Import PID digital display thermostat
4	Temperature control accuracy	60±0.1°C
5	Heating method	Electric heating tube
6	Working unit	4 groups
7	Timing mode	Digital timer
8	Total power	2500W
9	Instrument size	750*240*720mm
10	Net weight	38KG
