• Model NO.：HT-4706E-L
• Transport Package：Standard Exporting Wooden Package
• Trademark：DahoMeter
• Origin：Dongguan, China
• Production Capacity：300 Sets,Month

Specification

1) Electrode pressure: 1.0±0.05N

2) Electrode distance: 4.0mm ± 0.01mm, angle 60°±5

3) The electrode voltage of the leakage tracking test device is adjustable from 100 to 600V (48~60HZ), and the voltage drop is less than 10% when the short-circuit current is 1.0±0.1A.

4) Drop height: adjustable from 30~40mm

5) Drop size: 44~55 drops/1cm3 adjustable

6) Dropping time: 30s ± 5s,

7) The number of drops: 0~9999 times adjustable

8) Electric trace index test instrument leakage judgment: the loop current is greater than 0.5A and maintained for 2 seconds, the relay action cuts off the current, indicating that the sample is unqualified

9) Electrical trace index test machine test process: automatic control of test procedures, independent ventilation

10) Electric trace index test instrument studio volume: 0.1m3 (can be customized according to different standards 0.5 m3 or 0.75m3)

11) Outer dimensions of equipment: 630mm wide × 390mm deep × 750mm high

12) Power supply: AC 220V, 50Hz
