• Model NO.：GD-261D
• HS Code：9031809090
• Production Capacity：100sets,Month

Basic Info.

Model NO. GD-261D HS Code 9031809090 Production Capacity 100sets/Month

Product Description

Automated Pensky-Martens Flash Point Tester by ASTM D93 Pensky-Martens closed cup method


Introduction:
The Automated Pensky-Martens Flash Point Tester is designed and manufactured as per standards GB/T 261-2008 Determination of Flash Point - Pensky-Martens closed cup method and ASTM D93 Standard Test Method for Flash Point by Pensky-Martens Closed Cup Tester.
The Automated Pensky-Martens Flash Point Tester is used to make determination of the closed cup flash point of the petroleum products.


Features:
1. The Automated Pensky-Martens Flash Point Tester adopts LCD screen to display. Full English man-machine dialog interface. It can preset the parameters of expected flash point,sample mark number, atmospheric pressure, test date,etc.It has menu to prompt and input function of guide type.
2. The Automated Pensky-Martens Flash Point Tester adopts simulation tracking display the function curve of temperature rising and test time.It has prompt functions of English mis-operation,test date and test time.
3. The Automated Pensky-Martens Flash Point Tester is equipped with standard RS-323,485 computer port.The lower computer can save 100 groups of historical data. The test data can be saved for a long time, transmitted and modified if the instrument being connected with computer.
4. The Automated Pensky-Martens Flash Point Tester can correct the influence of atmospheric pressure and calculate the correction automatically.
5. Differential detection.Automatically correct the systematic deviation.
6. Automatically open the lid,ignite,detect and print test data.The test arm lifting up and down automatically.
7. It adopts electric ignition to fire light the gas flame.It will light only need to press the button.
8. Humanized design,beautiful and safe. Easy to operate.


Specifications:
1. Power supply: AC(220±10%)V, 50Hz

2. Flash point determination:  Range: Ambient to 300ºC; Repeatability: ≤3ºC; Reproducibility:≤6ºC; Accuracy:0.1ºC

3. Heating rate: Procedure A: (5~6)ºC/min, Procedure B: (1~1.6)ºC/min
                        Automatic control and manually adjustable.
4. Stirring rate: Procedure A: (90~120)RPM, Procedure B: (250±10)RPM
                        Automatic control and manually adjustable.
5. Igniting mode: Electric ignition. Gas flame diameter:3.2mm~4.8mm
6. Working condition: Ambient temperature: (10~40)ºC
                                    Relative humidity ≤80%
7. Maximum power consumption: 500W
8. Dimension: 520mm*360mm*310mm
