• Model NO.：KMH-36L
• Quality：Assurance
• After-Series：Free in a Year
• Factory Tour：Welcome
• Temperature Range：-50-150c
• Interrior Dimension(W*H*D)mm：300*400*300
• Exterrior Dimension(W*H*D)mm：460*780*1020
• Weight (Kg)：530
• Transport Package：Plywood Case
• Specification：Standard and Customized
• Trademark：KOMEG
• Origin：Dongguan China
• HS Code：90321000
• Production Capacity：1000sets,Year

Benchtop Climatic ChamberSecifications ( at +20ºC room temp.  Or+25ºC water temp with empty load)ModelKMH-36L36L chamber volumeTemp. range -50 ºC~+150ºCInterior sizelW(mm)300H(mm)400D(mm)300Exterior sizeW(mm)460H(mm)780D(mm)1020Power(KW)4.5Weight(KG)100Temp. constancy±0.5ºC   Temp. uniformity±2.0ºCHeat up time -50ºC~+150ºC, within 70 min  Pull down time +20ºC~-50ºC , within 60 min   Humidity Range20~98%R.HHumidity constancy±2.5%R.HStandard accessoriesSight window*1,  cable port(portΦ50mm)*1,   shelves*2,    chamber lamp*1,    power cable *2mSafety device  (standard)No fuse breaker, over pressureover heat and over current protection for compressor,Over temp. protect, over load protect of blower, dry heat protectionControl SystemBalanced Temperature & Humidity Control SystemRefrigeration systemAir Cooled (Water Cooled Type is option)Hermetic compressor,Single stage refrigeration system                       CFC-Free refrigerant(HFC-507/HFC-23)ControllerPanel:7-inch LCD Touch panel,    Chinese or English display selectableOperation model :Program or fix point runningMemory capacity :120programs,1200steps,All repeat 999 cycles, part repeat 99 cyclesInterior materialStainless Steel Plate(SUS 304)Exterior materialBaked Painting Steel Or Stainless steel(SUS304)Insulation materialRigid polyurethane Foam and Glass Fiber WoolAmbient Temp.+5ºC~+35ºCWiring methodAC220,50Hz ,1phase 2 wires +Ground WiresNote: 1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available
Standard configuration
Sight window*1, cable port(portΦ 50mm)*1, shelves*2, chamber lamp*1, power cable *2m
No fuse breaker, over pressure, over heat and over current protection for compressor,
Over temperature protection, over load protect of blower, dry heat protection

Optional accessories
Cable Port: Φ 100mm cable port is available
Shelves
RO-type water purifier: R-80/day
Provide to keep the humidifying heater and wet bulb wick free from scale.
Inner glass door with operation port
A glass door can be provided behind the main door so that specimens can be observed. Two operation ports of 130mm diameter are used for handing specimens inside the chamber without opening the glass door.
Dehumidifier
The rotation regenerating dehumidifier M-120 ensures precise control of low humidity (5 ° C 5%RH) for electrostatic reliability tests.
Temperature and humidity recorder
-100 to +150° C/0 to 100%RH 100mm with effective width 100mm and 2 pen
Temperature 1 pen and humidity 1 pen.
-100 to +150° C Celsius/0 to 100%RH 100mm with effective width 100mm and 6 dots
Temperature 3 dots and humidity 1 DOT.
-100 to +150° C/0 to 100%RH 100mm with effective width 180mm and 12 dots
Temperature 6 dots and humidity 6 dots.
Defrosting circuit
The chamber automatically detects and melts the frost on the evaporator when operating below 0Fahrenheit degrees Celsius
Liquid or infection
In order to rapidly decrease the temperature inside the chamber, a cylinder of liquid can be connected the chamber.
