• Model NO.：HJ-80
• Accuracy Grade：No
• Load Way：Electronic Load
• Loading Method：Static Load
• Display：Digital
• Control：Touch Screen Controller
• Weight：40kg
• Power Source：AC220V
• Oil Cylinder Position：No
• Angle Setting：5-180 Degrees
• Determine The Maximum Load：50kgf, Cm
• Minimum Decomposition Energy：0.01kgf.Cm
• Times Setting (Max)：999999
• Swing Speed (Max)：15 Times,Min
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-80 Accuracy Grade No Load Way Electronic Load Loading Method Static Load Display Digital Control Touch Screen Controller Weight 40kg Power Source AC220V Oil Cylinder Position No Angle Setting 5-180 Degrees Determine The Maximum Load 50kgf, Cm Minimum Decomposition Energy 0.01kgf.Cm Times Setting (Max) 999999 Swing Speed (Max) 15 Times/Min Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

Detailed introduction of shaft life testing machine
This machine can test the torque decline of the rotating shaft after opening and closing the notebook cover for many times. It can measure the torque value of the rotating shaft every time and record the curve change and draw the torque attenuation life curve. At present, the rotating shaft must be disassembled to measure the inconsistency of the torque. Convenience. Using the Windows window screen setting, the operation is simple and convenient, and all data can be stored (test conditions, torque angle graphs, life graphs, inspection reports, etc.), the setting conditions are all set by the computer screen (including angle, speed , times, pause time, etc.).


Angle setting	5~180 degrees
Determine the maximum load	50Kgf,cm
minimum decomposition energy	0.01Kgf.cm
Times setting (MAX)	999999
Swing speed (MAX)	15 times/min
Speed setting	stepless speed regulation
Machine size	730×635×790mm
Machine weight	90Kg
power supply	1∮220V, 5A or specified

      FAQ

1. Do you offer after-sales service? How can I ask for that? And how about the warranty?
   Every machine from our factory has a 12-month warranty after shipment. Generally,we offer 12 months for the FREE maintenance, while considering of sea transportation,If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem,we can send you new spare parts or provide on-site repair.

   2.. What's the delivery term?
   At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
