• Model NO.：GDOT-100C
• Control：Automatic contol
• Weight：0-100Kg
• Power Source：AC220V
• Output Voltage：100kV
• Power Input：AC220V± 20%, 50Hz±5Hz
• Capacity：1.5kVA
• Voltage Distortion Rate：less than 1%
• Voltage Increasing Speed：2kV,s, 3kV,s (optional)
• Application temperature：0~40 degree centigrade
• Transport Package：Wooden Case
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan China
• HS Code：9030899090
• Production Capacity：2000PCS,Year

Basic Info.

Model NO. GDOT-100C Control Automatic contol Weight 0-100Kg Power Source AC220V Output Voltage 100kV Power Input AC220V± 20%, 50Hz±5Hz Capacity 1.5kVA Voltage Distortion Rate less than 1% Voltage Increasing Speed 2kV/s, 3kV/s (optional) Application temperature 0~40 degree centigrade Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030899090 Production Capacity 2000PCS/Year

Product Description

Product Description

GDOT Insulation Oil Breaker Tester is fully digital industrial instrument with microcomputer control. It has the features of high accuracy and strong anti-interference ability.


Features

1. Adopts large-capacity single-chip, with reliable performance;
2. A wide range of watchdog circuit is set inside the instrument to prevent system failure;
3. The oil cup is made of special glass with once-step casting technique to prevent oil leakage and other interference phenomena;
4. Unique high-voltage sampling design allows test values to be in the A/D converter directly, which avoids errors caused in the analog circuit, more accurate;
5. The instrument has over current, over voltage, short circuit protection and other functions, and has a strong anti-interference ability, good electromagnetic compatibility;
6. Portable structure, easy to move, convenient for indoor and outdoor use.

Specifications


Output voltage	0-100kV
Voltage distortion rate	< 1%
Voltage increasing speed	2kV/s, 3kV/s (optional)
Capacity	1.5kVA
Power input	AC220V± 20%, 50Hz±5Hz
Power	<200W
Working temperature	0-40ºC
Humidity	≤85%RH
Dimension	410*390*380mm

Accessories


GDOT-100C instrument	1pc
Oil cup	1pc
Power cord	1pc
Ground cable	1pc
Spare fuse 3A	2pcs
Stirring nut	2pcs
Standard 2.5mm	1pc
Tweezer	1pc
Print paper	1 roll
User's guide	1pc
Factory test report	1copy
