• Loading Method：Dynamic Load
• Display：Digital
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC 110V,220V at Customized
• Oil Cylinder Position：Under
• Measuring Range：0~2 Ohm(10mA),2~20 Ohm(10mA),20~200 Ohm(1mA)
• Relative Humidity：0-85%Rh
• Transport Package：Carton or Plywood
• Specification：ISO9001 SGS
• Trademark：Sansion
• Origin：Wuhan, China
• HS Code：9030332000
• Production Capacity：100 Units

Working condition
 Temperature:0ºC~+45ºCRelative humidity:≤85%RHMeasuring range and constant current value (RMS)
 Resistance:0~2Ω(10mA),2~20Ω(10mA), 20~200Ω(1mA)Voltage:AC 0~20VMeasuring precision:0~0.2Ω≤±3%±1d0.2Ω~200Ω≤±2%±1d1~20V≤±3%±1dMeasuring resolution:0.001Ω, 0.01Ω, 0.1Ω, 0.01VAllowed auxiliary earth resistance :RC(between C1 and C2)<1.8KΩRP(between P1 and P2)<40KΩ Error ≤±5%Allowed earth voltage≤5V(power frequency RMS) Error≤±5%Max. Power consumption
 ≤2WPower supply:6.8V~9V(5# Cd-Ni rechargeable battery), or connect with 220V AC source.
Warranty: One year quality guarantee after shipment.
More details please kindly contact with Sansion Power.Thank you!
