Package Transportation Single Arm Drop Testing Machine
Guangdong Yuanyao Test Equipment Co., Ltd.- Max Diameter of Workpiece：700mm
- Mass Scope of Workpiece：<900kg
- Type：Drop Testing Machine
- Maxcapacity：<1000KN
- Accuracy Grade：0.5
- Load Way：Mechanical Load
Base Info
- Model NO.：YDT-200A
- Loading Method：Static Load
- Display：Digital
- Control：Controller
- Weight：500-1000Kg
- Power Source：AC380V
- Oil Cylinder Position：N,a
- Max. Load：100kg
- Max. Specimen Size：1200X1200X1200
- Drop Height：0-2000mm
- Test Way：Surface,Edge,Angle
- Control Type：PLC Control
- Machine Size：1400X2100X3250mm
- Impact Board Size：1400X2100X60mm
- Machine Weight：About 800kg
- Application：Large Package Drop Test
- Power Supply：AC 3 Phase 380V 50Hz
- Transport Package：Strong Plywood Case
- Specification：CE, TUV, SGS Certificate
- Trademark：Yuanyao
- Origin：Guangdong, China
- HS Code：90318090
- Production Capacity：100sets,Month
Description
Major specificationsModel YDT-150A YDT-200A YDT-150B YDT-200B Type Single arm supporting the specimen Test height(mm) 30-150 30 - 200 300 -150 300 - 200 Max. specimen size(mm) 1000*1000*800 Max. specimen weight 85 KG Overall weight 480Kg 550Kg 480Kg 550Kg Overall size(mm) 1500*1000*2250 Baseplate size 1500*1000*20 Control method By electronic controller box Dropping method Pneumatic cylinder Height display LCD display reads drop height Height adjustment Servo motor controlling precision guiding Buffer type Oil pressure absorbability Power AC220V 50Hz 1 Phase Comply with standars: ISO2248-72(E), JIS Z0202-87,GB/T4857, 5-92.
In addition to Transportation Package Drop Impact Testing Machine, we are also manufacturing:
Precision Oven Tester, Triple Type Temp. & Humi. Chamber, Temp. &Humi. Control Host, Air Thermal
Shock Tester, Liquid Thermal Shock Tester, Salt Spray Tester, Walk-in environmental Test Room, Temp.
Humi. &Vibration Conbined Test Chamber, Aging Oven Tester, Rain/Spray Test Chamber, Burn-in test
equipment, Dust Tester, Steam Aging Tester, Vibration Tester, Tensile Tester and so on.
Welcome to inquire and cooperate with Yuanyao!
