Different Frequency Transformer Tan Delta Tester Capacitance Dielectric Loss & Dissipation Factor Tester 10kv
Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.- Anti-Interference：Frequency Conversion
- Power Supply：AC 220V±10%,50,60Hz(or Customize)
- High Output：0.5~10kv
- Self-Excited Power：AC 0V∽50V,15A
- CVT Range：10~10000
- CVT Test：Cx < 300 NF
Base Info
- Model NO.：GDGS
- C X：15PF < Cx < 300NF
- Memory Size：The 200 Group Supports U Disk Data Storage
- Application：Transformer Tan Delta Test
- Transport Package：Plywood Case for Tan Delta Tester
- Specification：30KG
- Trademark：GOLD
- Origin：Chongqing, China
- HS Code：9030849000
- Production Capacity：500piece,Month
Description
GDGS Automatic Transformer Power Factor Tester
1
Use conditions
-15ºC∽40ºC
RH<80%
2
Anti-interference
Frequency conversion
3
Power
AC 220V±10%
4
High output
0.5KV∽10KV
Every 0.1kV
Precision
2%
Maximum current
200mA
Capacity
2000VA
5
Self-excited power
AC 0V∽50V/15A
45HZ/55HZ 47.5HZ/52.5HZ
55HZ/65HZ 57.5HZ/62.5HZ
Automatic double frequency
6
Resolving power
tgδ: 0.001%
Cx: 0.001pF
7
Precision
△tgδ:±(Reading*1.0%+0.040%)
△C x :±(Reading*1.0%+1.00PF)
8
measuring range
tgδ
Unlimited
C x
15pF < Cx < 300nF
10KV
Cx < 60 nF
5KV
Cx < 150 nF
1KV
Cx < 300 nF
CVT test
Cx < 300 nF
9
CVT range
10∽10000
accuracy
0.1%
Resolving power
0.01
10
Exterior dimension
350(L)×270(W)×270(H)
11
Memory size
The 200 group supports U disk data storage
12
Weight
28 Kg
