• Model NO.：48-B0192
• HS Code：90248000
• Production Capacity：5000 Sets,Month

Basic Info.

Model NO. 48-B0192 HS Code 90248000 Production Capacity 5000 Sets/Month

Product Description

    The Pendulum Skid Tester measures the frictional resistance between a rubber slider mounted on the end of a pendulum arm and the test surface. This provides highway engineers with a routine method of checking the resistance of wet and dry surfaces to slipping and skidding, both in the lab and on site.
    It is based on the Izod principle: a pendulum rotates about a spindle attached to a vertical pillar. At the end of the tubular arm a head of known mass is fi tted with a rubber slider.
    The pendulum is released from a horizontal position so that it strikes the sample surface with a constant velocity. The distance travelled by the head after striking the sample is determined by the friction of thesample surface.
    A reading of Skid Resistance is obtained.

Features
• Designed for laboratory and in situ road surface testing
• Dispatched calibrated to EN1097-8
• Low friction arm, and lightweight pointer
• Comes with integral 'F' scale for use with small slider set for 76mm slide length. (PSV test)
• Repeatable and reproducible
• Supplied with robust carrying case

Applications
• Road surface testing
• Testing of new road surface materials under development
• Testing of aggregates in the PSV (polished stone value) test
• Testing of fl oors and pedestrian walkways
• Flooring materials product development
• Accident investigations, both traffic and pedestrian
• Litigation investigations
