• Model NO.：BN-4000A,B
• Loading Method：Dynamic Load
• Display：Digital
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC220V
• Oil Cylinder Position：Under
• Load Cell：United States High-Precision Se
• Bearing：Japan NSK High-Precision Bearings
• Control Mode：Computer Temperature Control
• Fixtures：Sino-Foreign Joint Venture Germany West Pneumatic
• Report Content：Ml, Mh, Ts1, Ts2, T10, T30, T50, T
• Standard：ASTM D5289-95, ISO 6502
• Transport Package：Inner Packaging with PE Protective Film
• Specification：Electronic
• Trademark：Evertech
• Origin：Shandong, China (Mainland)
• HS Code：84778000
• Production Capacity：50 Set,Sets Per Month

Model

HZ-7001B Moving Die Foam Pressure Rheometer

Control temperature range

Normal temperature~200ºC

Temperature display resolution

0.01ºC(0.1 ºC common type of imported temperature controller temperature)

Temperature control accuracy

±0.3ºC

Calibration accuracy

Mooney value ±0.5

Rotor speed

2 rotation/ min ±0.02rotation/ min

Torque range

Mooney value 0~200

Torque resolution

 Mooney value 0.1

Print content

Date, time, temperature, Mooney scorch curve and MV,T5,T35,T3,T18,@15,@30

Power

50HZ, ~220V±10%

Computer Control Flat MDR Moving Die MDR Rheometer

Main technical specifications:

Temperature range: 0 ~ 200 ºC

Heating time: ≤ 10min

Mold body temperature fluctuation: ≤ ± 0.1 ºC%

Torque range: 0 ~ 20N.m

Swing frequency: 1.7Hz (100r.min-1)

Swing amplitude: ± 0.5 ° ± 1 °

Mold cavity structure: Monsanto form

Report contents: ML, MH, ts1, ts2, t10, t30, t50, t70, t90, vulcanization curve, temperature curve

Standard: ASTM D5289-95 ISO 6502: 1991 GB / T16584-1996

Power supply voltage: AC220V ± 10%

Dimensions: (L*W*H) 680mm * 650mm * 1100mm

Net weight 230Kg
