• Model NO.：SKZ131
• Loading Method：Dynamic Load
• Display：Digital
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC220V
• Oil Cylinder Position：Under
• Standards：ASTM D5289, ISO6502, T30,T60,T90
• 0,T90 Test Mode：Automatically, Controlled by Co
• Temperature Range：Room Temperature -- 300 ºC
• Warming Time：≤ 15min
• Temperature Resolution：0.1 C
• Temperature Fluctuation：0.5 C
• Torque Range：0n.M -- 10n.M
• Torque Display Resolution：0.001n.M
• Transport Package：Free Fumigation Ply-Wooden Case Outside
• Specification：Electronic
• Trademark：Evertech
• Origin：Shandong, China (Mainland)
• HS Code：84778000
• Production Capacity：300 Set,Sets Per Month

Temperature Resolution

0 to 200 °C: 0.1 °C

0 to 300 °C: 1 °C.

Temperature fluctuation

≤ ± 0.5 °C (after feeding)

Torque range

0N.m ~ 10N.m

Torque display resolution

0.001N.m

Maximum test time

120min (modify time during testing)

Swing angle

± 0.5 ° (total amplitude of 1 °)

Body swing frequency

1.7Hz ± 0.1Hz (102r/min ± 6r/min)

Power

AC220V ± 10% 50Hz

Dimension

645mm × 580mm × 1300mm (L × W × H)

Weight

220kg
