• Model NO.：GD-1094
• Test Purpose：Water-Miscible Components in Aviation Gasoline and
• Rated Voltage：AC220V +- 10% 50Hz
• Communication Terminal：RS232 Port
• Printer：Thermosensitive Micro-Printer
• Light Source：LED Lighting
• Amplitude Adjustment：120~250mm
• Speed Adjustment：2~4times , S
• Regular Time：115~125s
• Warranty：12 Months
• Transport Package：Wooden Case
• Origin：Chongqing China
• HS Code：9031809090
• Production Capacity：200 PCS , Month

Basic Info.

Model NO. GD-1094 Test Purpose Water-Miscible Components in Aviation Gasoline and Rated Voltage AC220V +- 10% 50Hz Communication Terminal RS232 Port Printer Thermosensitive Micro-Printer Light Source LED Lighting Amplitude Adjustment 120~250mm Speed Adjustment 2~4times / S Regular Time 115~125s Warranty 12 Months Transport Package Wooden Case Origin Chongqing China HS Code 9031809090 Production Capacity 200 PCS / Month

Product Description

Jet Fuels / Aviation Fuels Water Reaction Analysis Testing Equipment ASTM D1094




Test scope:

The test method ASTM D1094 covers the determination of the presence of water-miscible components in aviation gasoline and turbine fuels, and the effect of these components on volume change and on the fuel-water interface.

When applied to aviation gasoline, water reaction volume change using the technique reveals the presence of water-soluble components such as alcohols. When applied to aviation turbine fuels, water reaction interface rating using the technique is not reliable in revealing the presence of surfactants which disarm filter-separators quickly and allow free water and particulates to pass.


Introduction:

The GD-1094 Water Reaction Testing Equipment for jet fuel conforms to ASTM D1094 Standard Test Method for Water Reaction Tester of Aviation Fuel.
The Automatic water reaction tester is suitable for testing the presence of water-miscible components in aviation gasoline and turbine fuels, and the effect of these components on volume change and on the fuel-water interface.


Features:

1. The apparatus adopts of gas drive method to realize high speed reciprocating motion, it's China domestic initiative, compared with the traditional crank connecting
rod structure, our Water Reaction Testing Equipment features simple structure, low noise, low vibration, long life and portable use.

2. The Water Reaction Testing Equipment mainly consists of rodless cylinder, reversing valve, sensor and timing detection control system.

3. Our Water Reaction Testing Equipment selects highly reliable components, both collocation and selection approach the optimal solution, easy to maintain

4. The Water Reaction Testing Equipment also features small size, light weight, beautiful appearance, and built-in shaking cabin. Equips with transparent organic glass door, convenient for
observation. It can effectively prevent collision accident happens and protect
operator safety.

5. Brand New gas drive method makes the apparatus achieve stepless adjustment on shaking stroke control.

6. For shaking frequency, our apparatus adopts all time detection; it can adjust shaking frequency and record total shaking number by regulating compressor
capacity, that function provides accurate reference data of experiment.


Parameters:

1. Rated voltage:AC220V±10% 50Hz

2. Power: Electrical part 40W; Air supply part 1300w

3. Shaking frequency control: 10~500/min,It can be set as user requirement (Standard requires the experiment shake 2 ~ 3 times per second,that means 120 ~
180 times per minute).

4. Shake amplitude range:120~250mm(adjustable), resolution 5mm.

5. Timing range:115~125s adjustable(default is 120s)

6. Standing time:5min

7. Overall dimensions:440mm*440mm*735mm; weight: 45kg
