• Model NO.：KMH-408L
• Weight：100-500Kg
• Power Source：AC380V
• Control System：Touch Screen Controller
• Temperature Humidity Range：Programmable Temperature and Humidity
• Temp. Range：-40oc~+150oc or -104of~+302of
• Humidity Range：20-98%R.H.
• Temp. Constancy：+,-0.5oc
• Humidity Constancy：+,-2.5%R.H.
• Equipment Power：8.5kw
• Heat up Time：-40 Oc~+100 Oc Within 45mins
• Pull Down Time：+20 Oc~-40 Oc Within 60mins
• Power：AC380+,-10% 50Hz 3phase4wires+Groud Wires
• Transport Package：Strong Plywood Case, Meet International Standards
• Specification：Standard and customized, ISO9001, SGS, CE, TUV, UL
• Trademark：KOMEG
• Origin：Dongguan, China
• HS Code：90321000
• Production Capacity：1000 Sets,Year

Environmental Temperature and Humidity ChamberSecifications ( at +20ºC room temp.  Or+25ºC water temp with empty load)ModelKMH-R seriesKMH-L seriesKMH-S series1000R1000L1000STemp. range -20ºC~150ºC -40 ºC~+150ºC -70ºC~+150ºC Interior sizelW(mm)100010001000H(mm)100010001000D(mm)100010001000Exterior sizeW(mm)128012801280H(mm)216021602160D(mm)195019501950Power(KW)12.814.518.5Weight(KG)580600650Humidity uniformity±5.0%R.HHeat up time -20ºC~+100ºC,within 35 min -40ºC~+100ºC, within 45 min -70ºC~+100ºC,within 60 minPull down time +20ºC~-20ºC, within 45 min +20ºC~-40ºC , within 60 min +20ºC~-70ºC,within 80 minStandard accessoriesSight window*1, cable port(portΦ50mm)*1, shelves*2, chamber lamp*1, power cable *2mSafety device  (standard)No fuse breaker, over pressureover heat and over current protection for compressor,Over temp. protect, over load protect of blower, dry heat protectionControl SystemBalanced Temperature & Humidity Control SystemRefrigeration systemAir Cooled (Water Cooled Type is option)Hermetic compressor,Single stage refrigeration system                      CFC-Free refrigerant(HFC-507/HFC-23)ControllerPanel:7-inch LCD Touch panel,    Chinese or English display selectableOperation model :Program or fix point runningMemory capacity :120programs,1200steps,All repeat 999 cycles, part repeat 99 cyclesHumidity Range20~98%R.HTemp. constancy±0.5ºC   Humidity constancy±2.5%R.HTemp. uniformity±2.0ºCInterior materialStainless Steel Plate(SUS 304)Exterior materialBaked Painting Steel Or Stainless steel(SUS304)Insulation materialRigid polyurethane Foam and Glass Fiber WoolAmbient Temp.+5ºC~+35ºCWiring methodAC 380±10%50Hz ,3 phase 4 wires +Ground WiresNote: 1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available
