• Model NO.：STCZ-2
• Accuracy Grade：1
• Load Way：No
• Loading Method：No
• Display：Needle
• Control：Digital Display
• Weight：235kg
• Power Source：AC220V
• Oil Cylinder Position：No
• Product Name：Stcz-2 Wheel Rutting Tester (Wheel Tracker)
• Application：The Wheel Tracking Device Measures Rutting Resista
• Rolling Distance of The Grinding Wheel：42times, Min
• Movement Distance of The Testing Trolley：230mm
• Specimen Mould Size：300X300X50mm
• Measuring Range of The Displacement：0-40mm
• Wheel Rutting Test Time：1-999min
• Constant Temperature Controlling Range：Room Tempature -80c
• Transport Package：Wooden Case
• Specification：1.45CBM
• Trademark：SHTG
• Origin：China
• HS Code：9031809090
• Production Capacity：100PCS,Month

Basic Info.

Model NO. STCZ-2 Accuracy Grade 1 Load Way No Loading Method No Display Needle Control Digital Display Weight 235kg Power Source AC220V Oil Cylinder Position No Product Name Stcz-2 Wheel Rutting Tester (Wheel Tracker) Application The Wheel Tracking Device Measures Rutting Resista Rolling Distance of The Grinding Wheel 42times/ Min Movement Distance of The Testing Trolley 230mm Specimen Mould Size 300X300X50mm Measuring Range of The Displacement 0-40mm Wheel Rutting Test Time 1-999min Constant Temperature Controlling Range Room Tempature -80c Transport Package Wooden Case Specification 1.45CBM Trademark SHTG Origin China HS Code 9031809090 Production Capacity 100PCS/Month

Product Description

STCZ-2 Wheel Rutting Tester (Wheel Tracker)

Parameters.

Product name	STCZ-2 Wheel Rutting Tester (Wheel Tracker)
Application	The Wheel Tracking Device measures rutting resistance ability of asphalt mixture against high temperature and supplemental tests of asphalt mixture design.
Rolling distance of the grinding wheel	42±1times/ min
Movement distance of the testing trolley	230±10mm
Specimen mould size	300×300×50mm
Measuring range of the displacement	0-40mm
Wheel rutting test time	1-999min
Constant temperature controlling range	room tempature -80ºC
