Ep Hipot Electric AC Resonant Test Equipment for Cable Hipot Dielectric Test Machine
EP HIPOT ELECTRIC CO., LTD.- After-sales Service：Onsite and Remote Guidance
- Warranty：1or 2 Years Free Warranty Longlife Service
- Max Diameter of Workpiece：<500mm
- Mass Scope of Workpiece：<900kg
- Type：Strength Testing Machine
- Accuracy Grade：0.5
Base Info
- Model NO.：EPCZ Series
- Load Way：Electronic Load
- Display：LCD Touch Screen
- Control：Computer Control
- Weight：0-100Kg
- Power Source：AC380V
- Output Voltage：Customized
- Capacitance：Customized
- Output Frequency：30 -300Hz
- Working Duration：Can Be Customized
- The System Is Consisted by：Variable Frequency Power Supply
- Resonant Voltage Waveform：Sine Wave, Waveform Distortion Rate <1.0%
- Maximum Tested Product Current：Can Be Customized
- Maximum Test Capacity：Can Be Customized
- Working Time：Continuous Working Time Is 60min Under Full Power
- Quality Factor：30~90
- Input Working Power：Three-Phase 380V
- Ambient Temperature：-15~+40
- Relative Humidity：Less Than 90rh%, No Condensation
- Altitude：<5000m
- Noise：Less Than 50dB
- Transport Package：Plywood Case with Foam and Waterproof Plastics
- Specification：Customized
- Trademark：EP Hipot
- Origin：Wuhan, China
- HS Code：9030339000
- Production Capacity：500,Year
Description
Note:
- Model EPCZ-27/54/108-108, EPCZ is the model of series, 27/54/108 is: voltage of one reactor (kV)/voltage of two reactors in series connection/voltage of four reactors in series connection. 108 is the total capacity (kVA).
- The test object is the common configuration for reference only. For details, please contact with us.
- If the capacity of your equipment is small and voltage is too low, can add more reactors to increase the capacity, and add more divider to increase the test voltage.
