Portable Transformer Insulation Oil Tan Delta Tester GD6100
HV Hipot Electric Co., Ltd.- After-sales Service：Yes
- Warranty：1 Year
- Type：Strength Testing Machine
- Maxcapacity：1000V-2200V
- Accuracy Grade：2
- Load Way：Electronic Load
Base Info
- Model NO.：GD6100
- Loading Method：Dynamic Load
- Display：Digital
- Control：Automatic
- Weight：0-100Kg
- Power Source：AC220V
- Oil Cylinder Position：Top
- Conditions：-5; C -40; C Rh <80%
- Power Supply：AC 220V +,-10%
- High Output：1000V ~ 2200V Every 200V
- Accuracy：2%
- Capacity：50va
- Output Current：25mA
- Temperature Induction Furnace：Maximum Power 1500W
- Transport Package：Carton or Wooden Case
- Specification：ISO, SGS
- Trademark：HV Hipot
- Origin：Wuhan China
- HS Code：9030899090
- Production Capacity：2000PCS,Year
Description
Basic Info.
Model NO. GD6100 Loading Method Dynamic Load Display Digital Control Automatic Weight 0-100Kg Power Source AC220V Oil Cylinder Position Top Conditions -5; C -40; C Rh <80% Power Supply AC 220V +/-10% High Output 1000V ~ 2200V Every 200V Accuracy 2% Capacity 50va Output Current 25mA Temperature Induction Furnace Maximum Power 1500W Transport Package Carton or Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030899090 Production Capacity 2000PCS/YearProduct Description
Product DescriptionGD6100 Automatic Precision Oil Dielectric Loss Testers is a high-precision instrument of testing dielectric loss angle of insulating oil and other liquid, integrated with main components of cup oil of dielectric loss, temperature controller, temperature sensor, dielectric loss test power Bridge, AC test power, standard capacitors.
Features
1. Advanced high-frequency induction heating mode, heat evenly, fast speed, easy to control.
2. All digital technology, automated measurement.
3. 7-inch colorful LCD display, full English menu, the results can be printed.
Technical Specifications
| Conditions | -5ºC-40ºC, RH <80% |
| Power Supply | AC 220V +/-10% |
| High output | 1000V ~ 2200V every 200V |
| Accuracy | 2% |
| Capacity | 50VA |
| Output Current | 25mA |
| Temperature induction furnace | Maximum Power 1500W |
| Temperature control range | <100degree |
| Temperature measurement error | +/-0.5degree |
| Temperature error | +/-1degree |
| Temperature time | Less than 20mins, at room temperature to 90degree |
| Measuring range | Tgδ Unlimited, Cx 15PF ~ 300PF |
| Accuracy | Tgδ : +/- (1.0% of the reading + 0.020%) C x: +/-(1.0% of the reading+ 0.5PF) |
| Dimensions | 450 (L)*310 (W)*360 (H) |
| Weight | 18kg |
