Temperature Humidity Vibration Three Integrated Test Chamber (THV-1000)

Guangdong Komeg Industrial Co., Ltd.
  • Power Supply：380V ,220V
  • Certification：CE, ISO
  • Warranty：1 Year
  • Working Chamber Volume (L)：1000
  • Inner Size (D*W*H)Cm：100*100*100(Cm)
  • Temp. Range：-70oc~+150oc

Base Info

  • Model NO.：THV-1000
  • Temp. Constancy：< or =0.5oc
  • Temp. Uniformity：+,-2.0oc
  • Humidity Range：2.0%R.H.~98%R.H.
  • Cooling Rate：Less Than 5oc,Min or Less Than 10oc,Min
  • Interior Material：Stainless Steel Plate(SUS304)
  • Exterior Material：Baked Painting Steel or Stainless Steel (SUS304)
  • Insulation Material：Rigid Polyurethane Foam
  • Transport Package：Strong Plywood Case, Meet International Standards
  • Specification：Standard and Customized
  • Trademark：KOMEG
  • Origin：Dongguan, China
  • HS Code：90321000
  • Production Capacity：1000 Sets Per Yesr

Description

temperature/humidity/vibration Multi-Functional Integrated Testing ChamberSpecifications  THV-4081000Working chamber volume ( L )4081000Interior size ( W*H*D ) mm600*850*8001000*1000*1000Safety deviceNo fuse breaker, overpressure overheat and over current protection for compressor,Over temp. protection, overload protection for the blower,Hydraulic and Water lack Protection dry heat protectionPowerAC 380V/50Hz,3phase 5 wires+ ground wire Temp regulating modeBalanced Temperature & Humidity Control System ( BTC )Ambient temp +5 ºC~ +35 ºCPerformanceTemp range -70 ºC~ +150 ºCTemp constancy≤0.5 ºCTemp uniformity±2.0 ºCHumidity constancy±2.5%RHHumidity range2.0%RH ~ 98%RHHumidity uniformityIf humidity≤75%RHJ, ±3.0%RH ; f humidity > 75%RHJ, ±5.0%RHCooling rate≤5  ºC /Min or ≤10  ºC /Min  ( -55 ºC~ +80 ºC  within humidity range )MaterialExterior materialCold-rolled steel sheet (Rustproof & Plastic Spray treated )/ Stainless Steel plateInterior materialStainless steel plate(SUS 304)Insulation materialRigid polyurethane foamCooling systemcompressorSemi-Hermetic CompressorCooling modeWater-cooledHeaterIron-chrome wire heaterBlowerCentrifugal BlowerSight window470mm*350mm   Glass incorporating heat generatorTemp sensorPt-100 ControllerTouch screen controllerShaking tableCustom made as requiredNote:
1. We reserve the right to change specifications without prior notice
 2. Customized sizes and configurations available                                                                Temperature Humidity Vibration Three Integrated Test Chamber (THV-1000)
Temperature Humidity Vibration Three Integrated Test Chamber (THV-1000)Temperature Humidity Vibration Three Integrated Test Chamber (THV-1000)Temperature Humidity Vibration Three Integrated Test Chamber (THV-1000)Temperature Humidity Vibration Three Integrated Test Chamber (THV-1000)
Packaging
Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside.

After-sale service
If you face any problems in the future during the testing process we promise we will give you a reply within 48 hours and the solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-conference. If customers require on-site service, the transport and travel expense shall be borne by the customer.

Our customers
HUAWEI, FOXCONN, OMRON, Siemens, SGS,INTERTRK, TUV, BV, Epson, Gree, TCL, LG, Edifier, etc.
