300kn/10kn Automatic Flexural and Compression Testing Machine
Zhuozhou Tianpeng Imp. & Exp. Trade Co., Ltd.- Type：Compression Testing Machine
- Maxcapacity：<1000KN
- Accuracy Grade：1
- Load Way：Electronic Load
- Loading Method：Dynamic Load
- Display：Digital
Base Info
- Model NO.：HYE-300BC
- Control：Computer Control
- Weight：100-500Kg
- Power Source：AC220V
- Oil Cylinder Position：Under
- Transport Package：Wooden Box or Others
- Trademark：Tianpeng
- Origin：China
- HS Code：90248000
- Production Capacity：1000 PCS,Year
Description
Loading capacity
Compression
300KN
Flexure
10KN
Constant-loading speed
Compression
0.3KN/S ~ 9.9KN/S
Flexure
0.05KN
Relative indication error
±1%
Rated pressure of the hydraulic pump
25Mpa
Diameter of flexure test shafts
Φ30mm
Distance between center points of upper and lower flexure test shafts
165mm
Distance between center points of 2 upper flexure test shafts
150mm
Distance between center points of 2 lower flexure test shafts
450mm
Span between support bases
100mm
Diameter of bearing platen
Φ155mm
Max. distance between upper and lower platen
230mm
Max. piston stroke
Compression
60mm
Flexure
80mm
Diameter of piston
Φ125mm
Motor power
220V 50Hz 1ph 0.75KW
Dimensions
1200mm×550mm×1400mm
Net weight
About 400kg
Compression Clamping device:
Flextural clamping device:
