Battery Short-Circuit Test Chamber/Lithium Battery Short-Circuit Tester
Dongguan Hongjin Test Instrument Co., Ltd.- Certification：CE, ISO
- Warranty：1 Year
- Custom Made：Customizable
- Impulse Voltage：AC 1kv,1.2-50us (Peak) Lmin
- Action Characteristics：Cold State Pull-in Voltage 66%Us
- Voltage Resolution：0.01V
Base Info
- Model NO.：HJ-68
- Transport Package：Fumigation-Free Standard Export Wooden Box
- Trademark：Hongjin
- Origin：China
- Production Capacity：1000 Sets, Month
Description
Data collection frequency7.19.1.10mslhr, 19 kinds can be set (if the test channel is more than
15 channels at the same time, the acquisition frequency can be set as
20ms-1hr) 7.19.2. Due to the high frequency of data collection, the data read and
recorded by the device in real time can be consistent with the actual data Runtime recording accuracy ≤±0.1% (full scale) Test Data The voltage/current/temperature data is displayed and recorded on the control
software in real time, and the voltage/current/temperature/time curve is
automatically drawn way to control Using remote touch screen control + remote control + computer (for data
analysis and video monitoring) short circuit Mechanical pull-in (contactor pneumatic pull-in, synchronous forced disconnection
device when disconnected) + vacuum arc extinguishing device Short circuit cut-off condition Short circuit can be stopped by setting voltage and time parameters Device circuit resistance <5m,>5m&<10m,>10m&<20m,>40m&<50m,>80m&<100m, the corresponding
rated test currents satisfy 10000A, 10000A, 5000A, 5000A, 3000A, respectively.
It includes the electrical components inside and outside the device + the internal
resistance of the cable + the internal resistance of the fixture. Short circuit terminal wiring <5m,>5m&<10m,>10m&<20m,>40m&<50m,>80m&<100m, 1 pair each,
The length of the wrong line is not less than 6 meters, and there are 5 pairs in total.
The cross-sectional area of the soft copper wire at the output end of the device is not
less than 2000mm² Short circuit internal resistance switching mode Manual switching, one end of the short-circuit terminal wire is a through nose,
which can be fixed by bolts with the screw holes of the contactor, and the other
end is a battery clamp with copper terminals, which can be directly clamped on
the positive and negative poles of the battery to replace It can be replaced by
simply removing the fixing bolts Short circuit test response time
(short circuit start to close to fully closed) ≤10ms Mechanical life 300,000 times Electrical life 50,000 times Remote control distance No solid barrier 10m short circuit time 0-9999H59M59S can be set
FAQ
1.Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 12-month warranty after shipment. Generally,we offer 12 months for the FREE maintenance, while considering of sea transportation,If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem,we can send you new spare parts or provide on-site repair.
2.. What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
