• Model NO.：TST-226A
• Accuracy Grade：Not Specific
• Load Way：Electronic Load
• Loading Method：Not Specific
• Display：Digital
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC380V
• Oil Cylinder Position：Not Specific
• Test Weight(Kg)：5kg
• Interrior Dimension(W*H*D)：610*730*510mm
• Basket Dimension (W*H*D)：510*510*510
• Low Temp. Chamber：-55 Oc~-10 Oc
• Pre-Cold Time：+20 Oc~-50 Oc Within 60mins
• Test Chamber：-40 Oc~+150 Oc
• Institutional Transfer Time：Within 10seconds
• Recovery Time(High Temp.)：Exposure 30mins
• Recovery Time(Low Temp.)：Exposure 30mins
• Recovery Time：Within 5mins
• Transport Package：Strong Plywood Case, Meet International Standard
• Specification：Standard and Customized
• Trademark：KOMEG
• Origin：Dongguan China
• HS Code：90321000
• Production Capacity：1000 Sets,Year

Two-Zone Thermal Shock ChamberSpecificationsNote:1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available                                                                                                                  ModelTST-D Series70D130D226D360D500DTest weight (KG)555510Interior sizeW(mm)410520610710810H(mm)560670770830710D(mm)410520610770860Basket   sizeW(mm)300410510610710H(mm)300410510730610D(mm)300410510510730High Temp. Chamber +60ºC~+200ºCLow Temp. chamber -80ºC~-10ºCPre-heat time +60ºC~+200ºC,Within 25 minPre-cold time +20 ºC ~ -70ºC,Within 60 minTest. chamber -65ºC ~ +150ºCRecovery timeHigh-Temp Exposure 30 minsLow-Temp Exposure 30 minsRecovery time within 5 minsInstitutional Transfer timewithin 10 secondsInterior materialStainless steel plate(SUS 304)Exterior materialBaked painting steel or stainless steel(SUS304)Insulation materialRigid polyurethane Foam+glass fiber woolRefrigeration systemWater CooledSemi-hermetic compressor, cascade  refrigeration system, CFC free refrigerant
( HFC-507 and HFC-23 )ControllerPanel:7-inch LED Touch panel , Chinese or English display selectableOperation model:Program or fix point runningMemory capacity:120programs,1200steps,all repeat 999cycles , part repeat 99 cycles.Accuracy:Temp.:0.1% of F.S±1 digit     Humidity:0.1% of F.S±1 digitInput:Temp.:pt-100,Humidity:pt-100 or  ~ 5V DCVSafety deviceNo fuse breaker, over pressure,over heat and over current protection for compressor,over temperature protection,over load protection for blower, dry heat protectionStandard accessoryCable port(portΦ50mm)*1,   shelves*2, Ambient Temp.+5 ºC ~ +35ºCPowerAC 380±10 %  50Hz ,3 phase 4 wires +Ground Wires
After-sale service
If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-conference. If customers require on-site service, the transport and travel expense shall be borne by customer.
