Laboratory Distillation Apparatus ASTM D1160 Vacuum Distillation Apparatus for Crude Oil

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
  • Display：Digital
  • Weight：0-100Kg
  • Power Source：AC220V
  • Product Name：ASTM D1160 Vacuum Distillation Apparatus for Petro
  • Standard：ASTM D1160
  • Measurement Range：Ambient~100celsius

Base Info

  • Model NO.：GD-0165
  • Refrigeration：No
  • Single/Double Unit：LCD
  • Atmospheric/Vacuum：Vacuum
  • Usage：Determine The Distillation Characteristics
  • Delivery Time：10 Working Days(If Urgent, We Can Push)
  • Test Parameter：Petroleum Products
  • Transport Package：Wooden Case for ASTM D1160 Vacuum Distillation APP
  • Trademark：GOLD
  • Origin：Chongqing, China
  • Production Capacity：100 Sets, Month

Description

1Power supplyAC(220±10%)V, 50Hz2Heating powerHeater for distillation flask:1000W,Heater for receiver:350W3Heating furnace of distillation flask(0~1000)W, adjustable4Temperature control point of air bath of receiverAmbient to 100ºC, adjustable5Temperature sensor of air bathPt100,RTD6Temperature control modeDigital temperature controller7Temperature control precisionSet temp.±1ºC8Capacity of buffer vessel1000ml9Max.Residual pressure2mmHg10Digital pressure gauge(0~200)mmHg11Illumination light in the air bathEnergy saving lamp12Working condition:Ambient temp(5~35)ºC    RH:< 85%13Dimension580mm×230mm×605mm



Related Products:

ParameterGD-6536AGD-6536BGD-6536CGD-0165
StandardsASTM D86ASTM D86ASTM D86ASTM D1160
Measurement rangeAmbient temperature~400ºC0~60ºC0~60ºCAmbient temperature~100ºC
Precision±0.5ºC±0.5ºC±0.5ºC±1ºC
RefrigerationNoYes(compressor)Yes(compressor)No
Single/Double unitDoubleDoubleSingleLCD
Atmospheric/VacuumAtmosphericAtmosphericAtmosphericVacuum
