• Model NO.：GD-0620B
• Sample Quantity：4 Pieces
• Measurement Range：18~580000PA.S
• Transport Package：Wooden Case for Asphalt Dynamic Viscometer
• Trademark：GOLD
• Origin：China
• Production Capacity：100 Sets, Month

Basic Info.

Model NO. GD-0620B Sample Quantity 4 Pieces Measurement Range 18~580000PA.S Transport Package Wooden Case for Asphalt Dynamic Viscometer Trademark GOLD Origin China Production Capacity 100 Sets/ Month

Product Description

Asphalt Dynamic Viscometer to determine Dynamic Viscosity of Petroleum Asphalt ASTM D2171



The bitumen dynamic viscometer covers procedures for the determination of the dynamic viscosity of asphalt binder by vacuum capillary viscometers. It is applicable to materials having viscosities in the range from 0.0036 to over 20000 Pa·s.



I.Summar:
  This bitumen dynamic viscometer is made as per standards ASTM D2171 Dynamic Viscosity Test for Bitumen (Vacuum Capillary Method). It is suitable to determine the dynamic viscosity of sticky petroleum asphalts by vacuum capillary viscometer. It is also used to determine other materials which viscosity range is 0.0036~20.000Pa.s.



II. Main technical features:
1. It can save 10 groups of coefficients at most. Operator can callout the data whenever need.

2. It adopts high accuracy pressure sensor. The vacuum degree can be kept at 300mmHg±0.5mmHg. It can be shown on the screen clearly.

3. The system will ignore the results which timing is less than 60s and enter next measurement step. The system will calculate the viscosity automatically for the results which timing is beyond 60s.

4. Operator can choose and set automatic calculation of average value and bias percentage for 2~4 parallel tests at will.The calculation can be done for several times to remove the unsatisfied results for operator. The test report can be printed.




III. Main technical specifications


1	Temperature control range	0~100ºC
2	Accuracy	0.01
3	Pressure range	300±0.5mm Hg
4	Timing range	0~999s
5	Sample quantity	4 pieces
6	Measurement range	18~580000Pa.s
7	Timing mode	4 built-in timer. Can do timing for 4 capillary viscometers
8	Operation interface	Touch-type colored LCD
9	Power supply	AC(220±10%)V , 50Hz
10	Overall dimension	590mm×430mm×630mm
11	Net weight	32.5kg(no water in bath)
12	Features	Auto control the temperature and vacuum, with the functions of store, calculate, print the test result and test time

IV.Asphalt testing instrument

Penetrometer series
Asphalt softening point tester series
Asphalt ductility tester series
GD-0620A Asphalt dynamic viscometer
GD-0613A Automatic breaking point apparatus
GD-0624 Asphalt tenacity tester
GD-0615 Petroleum asphalt wax content tester
GD-0610 85 Type asphalt rolling thin film oven
GD-0609 82 Type asphalt rolling thin film oven
GD-0621 Asphalt standard viscometer
GD-0623 Saybolt viscometer
GDE-1B Engler viscometer
GD-0709 Marshall stability tester
GD-0709A Marshall stability tester
GD-0752 Wet wheel abrasion tester
GD-0754 Cohesion tester
GD-0755 load wheel rolling tester
GD-F02-20 Automatic mixture blender
GD-0702 Marshall electric compactor
GD-0703 wheel-track modeling machine
GD-6307 Asphalt content tester
GD-0719 Automatic wheel-track tester(common type)
GD-0722 Centrifugal extractor
GD-0711A Bituminous mixtures theoretical maximum specific gravity tester
