• Model NO.：GD-5453
• ASTM D5453 Sulfur Content：Sulfur in Fuels Tester by ASTM D5453
• Measuring Range：(0.2~8,000)Mg,L
• Applications：Engine Fuels, Engine Oil
• Boiling Range of Samples：Approximately 25c to 400c
• Sample Types：Liquid Hydrocarbons
• Viscosities of Samples：0.2~20 Cst (mm2,S) at Room Temperature
• Transport Package：Plywood for Total Sulfur Content Analyzer
• Origin：Made in China
• HS Code：9031809090
• Production Capacity：100sets,Month

Basic Info.

Model NO. GD-5453 ASTM D5453 Sulfur Content Sulfur in Fuels Tester by ASTM D5453 Measuring Range (0.2~8,000)Mg/L Applications Engine Fuels, Engine Oil Boiling Range of Samples Approximately 25c to 400c Sample Types Liquid Hydrocarbons Viscosities of Samples 0.2~20 Cst (mm2/S) at Room Temperature Transport Package Plywood for Total Sulfur Content Analyzer Origin Made in China HS Code 9031809090 Production Capacity 100sets/Month

Product Description

Total Sulfur Test in Light Hydrocarbons and Engine Fuel by ASTM D5453



Test Significance:

Sulfur plays a negative role in the production processes of refineries. Process catalysts used in petroleum and chemical refining can be poisoned when trace amounts of sulfur bearing materials are contained in the feedstocks. The sulfur is being removed from petroleum distillates to reduce sulfur dioxide (SO2) emissions when fossil fuels are combusted and in order to protect catalysts in the refining process. Regulating bodies have set challenging low levels of allowed Sulfur concentrations in fuels to protect the environment.

Total Sulfur Test by UV-Fluorescence provides superior repeatability and the highest accuracy. The lowest possible uncertainty of the actual concentration provides better insight over the sulfur content during analysis.


Standards:

ASTM D5453 Method specifically for the petroleum industry, covering the determination of the total sulfur content in liquid petroleum products by ultraviolet fluorescence detection.
ASTM D5453 Formula: The maximum Std dev for 9 mg/kg Sulfur is 0.5 mg/kg (Std dev ≤ 1.5 * (r / 2.77)). At the level of 9.0 mg/kg, r=0.93 based on the formula r=0.1788*.75.

Parameters:

1. Working range of Total Sulfur: 0.2 - 8,000 mg/kg
2. Boiling range: 25 - 400°C
3. Viscosities of samples: 0.2 - 20 cSt (mm2/s) at room temperature
4. Sample types: Naphthas, Distillates, Engine Oil, Ethanol, Fatty Acid Methyl Ester (FAME); Engine Fuel such as Gasoline, Oxygen Enriched Gasoline (Ethanol Blends, E-85, M-85, RFG), Diesel, Biodiesel, Diesel/Biodiesel Blends, Jet Fuel
5. Measuring accuracy:

Concentration values (ppm)	Injection quantity (µL)	RSD (%)
0.2	20	50
5	10	10
50	10	5
100	10	3
5000	10	3

Picture of ASTM D5453 Total Sulfur Analyzer:
