• Model NO.：YSRT-1728-A
• Water Spray Hole Quatity：25PCS
• Sample Table Rotation Speed：1r--5r,Min
• Time Setting：0-9999h
• Water Spray Pipe Radius：375,500mm
• Materials：Stainlsss Steel
• Test Standard：Ipx3
• Application：Light,Lamp, Auto Parts, Electronics, etc.
• Transport Package：Strong Wood Carton
• Specification：IEC60529
• Trademark：Yuanyao
• Origin：China
• HS Code：9031809090
• Production Capacity：100 Sets,Month

SpecificationModelYSRT-1728-AYSRT-1728-E(IEC-529)(CNS14165) Internal Dim.WHD(mm)1200×1200×12001200×1200×1200 External Dim.WHD(mm)1750×1850×13001750×1850×1300 Water Temp.NormalNormal
Spray Type
Total water
 flow(L/min)R11.8IP×1With in 1--1.5mm/min(In drip box)R23.2IP×2With in 3--3.5mm/min(In drip box)S124.5IP×3angle±600,R:400mm,1.1L/minS239.2IP×4angle±1800,R:400mm,1.8L/min
Preesure of
spray nozzle
(kgf/cm 2 )R10.11.Flow rate of the water=0.07L/min
2.IP×3,Radius:400mm,Number or open holes=16,total water flow:1:1L/min.
3.IP×4,Radius:400mm,Number or open holes=25,total water flow:1:8L/min.
*Radius:200mm,R400mm.(For IP×3,IPx4)R20.3S11S23(RPM)Test Specimen Frame17RPM1RPM
   Spray Nozzle Rotation Speed23RPM
Swing 60°from vertical for 4 seconds at one time

Swing 180°from vertical for 12 seconds at one time
   Material InteriorSUS#304 Exterior Other ComponentsChamber lamp.Wiper
casters with AdjustersChamber lamp.Wiper,casters with Adjusters Power Source[K.W]AC 1Ψ 220V 60/50Hz 4KW

Except Rain Spray Test Chamber, Dongguan Yuan Yao Electronics Technology Co., Ltd also can supply:

Precision Oven Tester, Triple Type Temp. & Humi. Chamber, Temp. &Humi. Control Host, Air Thermal Shock Tester, Liquid Thermal Shock Tester, Salt Spray Tester, Walk-in environmental Test Room, Temp. Humi. &Vibration Conbined Test Chamber, Aging Oven Tester, Rain/Spray Test Chamber, Burn-in test equipment, Dust Tester, Steam Aging Tester, Vibration Tester, Tensile Tester, Drop Tester and so on.
