• Model NO.：WKL-3000
• Loading Method：Dynamic Load
• Display：Digital
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Top
• Transport Package：Wooden Case
• Specification：600mm*460mm*430mm
• Trademark：GOLD
• Origin：China
• HS Code：9031809090
• Production Capacity：200unit,Month

Bias voltage range: 0 ~ 500mv Measuring range:

S:0.05 ~10000 ng/µl

Cl:0.2~10000 ng/µl

Air source requirements: Industrial nitrogen(99.9%), industrial oxygen(99.9%) Temp control:  Ambient to 1000ºC,  ±1ºC  Power supply: AC 220V±22V,50HZ±0.5HZ; power consumption 3.5KW   Dimension: 700mm×480mm×540mm (PC is not included) Net weight:  46Kg



Measuring accuracy:

Sample concentration (ng/µl)Inject Volume(µl)RSD (%)0.210

30

1.0101010053100052









I. Main technical features



1. Micro-coulometry technology. PC equipped. Windows OS.Easy to operate.



2. Oxidation style. It determines the sulfur or chlorine in petrochemicals as per Faraday's Law.



3. Wide application scope and good adaptation. It can be used to determine the sulfur or chlorine in liquid, gas or solid materials.



4. Self-developed operation and test software. It will complete the data collecting, processing, saving and printing automatically.



5. It needs less sample. Only 10μl for each test. The testing time is short. Only 1-2 minutes for each sample.





• Sulfur Content Tester Selection List



ItemGD-380B Sulfur Content Tester

GD-4294C X-ray

Fluorescence

Sulfur-in-Oil Analyzer

GD-0689 Ultraviolet Fluorescence
Sulfur-in-Oil AnalyzerGD-0253A Coulometric Sulfur AnalyzerPicture    Standards

ASTM D1266

Lamp method

ASTM D4294

 X-ray Fluorescence (XRF)

ISO 20846,ASTM D5453,ASTM D4629,ASTM D5762,ASTM D6069

Ultraviolet Fluorescence method

ASTM D3120,

ASTM D3246

ApplicationUsed to determine the sulfur content in
light oils(such as gasoline,kerosene)
which the Reid vapor pressure is not
higher than 600mmHg

Used to detect diesel,naphath,kerosene,

residual
oil,lubricant base oil,hydraulic oil,jet fuel,crude
oil,motor gasoline,and the sulfur content of other
distillate hydrocarbon.

Suitable to determine the total sulfur
content of liquid state hydrocarbon at
boiling range 25-400°C and the viscosity
0.2-10mm2/s at room temperature.Used
in total sulfur content range 1.0-
8000mg/kg naphth,distillate oil,engine fuel
and other oilsSuitable to determine the light petroleum
products at the boiling range 40-310°C.The
sulfur content range 0.5-1000ppm.If above
1000ppm sulfur content sample,detecting it
after attenuation.Not used in more than 10
times sulfur content of halogen
content,more 10% total nitrogen
content,heavy metal content more than
500ppm sample





• Workshop

*Over 10 years trading experience of Lab instruments
*50 years experience in R&D and manufacturing Cast GOLD Brand
*Passed ISO9001 international quality system certification
*Mainly develop and produces analyzing instruments for petroleum Products and Asphalt
analyzing equipments for Highway Engineering.
*our companys productions have become highly intelligentized and widely cover.With strong
technical force and strong development, new products have been launched continuously.


• Gold Equipment Service:

If you face any problems in future during testing process we promise we will give you a reply within 48 hours and

solution provide within 3 working days.

We can offer operation video and English operation muanual. We can provide video-con.

Onsite Service:

1.Device installation;

2.Equipment Operation Test Technology training;

3.Equipment Calibration;

4.Daily maintenance and maintenance of equipment

Free technical training for visiting factories

24-hour Online contact

Free software upgrades

Free information:steel tensile test

1.Product Instruction;

2.Product operation instruction/video;

3.Experiment Test (test application, test report)

Device Problem Handling:

1. Social media 24 hours online communication;

2. Mail Seamless Docking;

3. Video Conferencing;

4. Artificial free door-to-door service



• Exhibition

We have developed sales channels in many countries such as UAE, Saudi Arabia, Iran, Malaysia, Thailand, Pakistan,

India, Germany, Belgium, USA, Mexico, Kenya,

Nigeria, South Africa and other countries worldwide. And we have gained strong advantage and high reputation in international market.

After several years' development, our products have become high intelligent and wide coverage.
And our company has become one of the leading manufacturer of petroleum testing instrument and electrical testing instrument.

Brazil ANALITICA LATIN AMERICA 2017 2017 Photos Show



• Packing

Goods are packed in veneer case, which is firm and safe for overseas shipment.

Please feel FREE to contact us if you have any needs. And welcome to visit our OFFICIAL WEBSITE at:

http://chinainstrument.en.made-in-china.com
